▶ EngineEngine Manufacturer Kubota John Deere Engine Model V2403-CR-TE4-GL1 CD3029DLV50 Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged 3-cylinder, naturally aspirated, direct injection, liquid-cooled diesel No. of Cylinders 4 3 Displacement 148.5 in³ 179 in³ Rated Engine Speed 2700 rpm 2400 rpm Engine Power (Gross) 52 hp 53 hp PTO Power 44 hp 45 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element Dry type with safety element Fuel System Electronic Common Rail System (CRS) Direct injection, rotary injection pump, electric shutoff Alternator 45 A, 12 V 40 A ▶ HydraulicsPump Type Tandem pump - gear type Tandem gear pump Implement Flow 9.8 gpm 11.4 gpm Steering Flow 4.9 gpm 6.8 gpm Total Hydraulic Flow 14.7 gpm 18.2 gpm Overall Hydraulic Pump Flow 14.7 gpm 18.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.4 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position Not Published ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 18 gal (open station); 22 gal (cab) Coolant Capacity 8.7 qt 10 qt Crankcase Capacity 9.9 qt 9 qt Transmission / Hydraulic System Capacity 11.9 gal 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) Front Axle Fluid Capacity Not Published 5.3 qt (MFWD differential housing); 0.63 qt (each wheel hub) ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch PTO Rear 540 rpm @ 2550 engine rpm 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) Mid-PTO Availability Optional Not Published Category, 3-Point Hitch SAE Category I & II Category I and II Hitch Lift Capacity 3,858 lb Not Published Hitch Lift Capacity (at 24”) 2,976 lb 3,374 lb Lift Control Type Position control Position and depth control, top link draft sensing ▶ Transmission & DrivetrainTransmission Type Glide Shift CollarShift standard; SyncShuttle optional; PowrReverser optional No. of Speeds 12Fx8R 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) 16.5 mph 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) Max Travel Speed (Reverse) 15.8 mph 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) Clutch Dry type single stage Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Differential Lock & Limited Slip Options Rear differential lock, standard Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS; cab optional; two-wheel drive or MFWD Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type, mechanically activated Wet disk, self-equalizing, self-adjusting Seat Suspension & Adjustability Suspension seat with swivel function Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Two-wheel drive or mechanical front wheel drive (MFWD) Front Axle Rating Not Published 2,720 to 4,700 lb (2WD, by front tire, no loader); 2,760 to 4,620 lb (MFWD, by front tire, without loader) Drawbar Capacity 1,433 lb 1,675 lb (maximum permissible static vertical load, drawbar fully extended) ▶ Dimensions & ManeuverabilityOverall Width 67.3 in 94.6 in (maximum) Wheelbase 75.4 in 80.7 in Ground Clearance 15.4 in 19 in (2WD front axle); 17 in (MFWD front axle); 14.3 in (drawbar) Min. Turn Radius without Brakes 9.2 ft (with brake applied) 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) Height to Top of ROPS 98.0 in 88.7 in (extended) Height to Top of ROPS (folded) Not Published 76.7 in Height to Top of Cab Model Not Published 97 in Overall Length 135.0 in (with 3-point hitch) 122.6 in (2WD); 125.9 in (MFWD) (less drawbar and front weights) (without 3-point hitch) ▶ WeightTractor Weight (Base) 3,979 lb 4,370 lb (2WD); 4,730 lb (MFWD); add 1,000 lb with cab Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 18.4-16.1 R1 Agricultural - Front 9.5-16 8.3-24 (MFWD) R1 Agricultural - Rear 14.9-26; 13.6-28 13.6-28 R3 Turf - Front 29X12.50-15 Not Published R3 Turf - Rear 44X18-20 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Not Published Loader Model LA1055 521; 541; 541 self-leveling; 542; 542 self-leveling Loader Lift Height 112.7 in (at pivot pin) 521: 122 in; 541: 126 in; 541 self-leveling: 130 in Loader Lift Capacity (Full Height) 2,361 lb (at pivot pin) 521: 2,500 lb; 541: 2,500 lb; 541 self-leveling: 2,800 lb (full at pin) Loader Breakout Force 3,171 lbf 521: 3,485 lbf; 541: 3,484 lbf; 541 self-leveling: 4,125 lbf (at pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
