▶ EngineEngine Manufacturer Kubota Kubota Engine Model V1505-CR-TE5-D40R5 V1505-E3-D24H Engine Type Turbocharged, direct injection, liquid-cooled diesel Indirect injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 4 4 Displacement 91.4 in³ 91.5 in³ Rated Engine Speed 2700 rpm 2700 rpm Engine Power (Gross) 34.9 hp 33 hp PTO Power 28.7 hp 25 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Pressurized radiator Water-cooled Air Cleaner 6 in paper filter (with dual element) Dual paper element Fuel System Direct injection Indirect injection Alternator Not Published 14.5 A, 12 V ▶ HydraulicsPump Type Dual pump Not Published Implement Flow 5.4 gpm 6.7 gpm Steering Flow 4.1 gpm 3.2 gpm Total Hydraulic Flow 9.5 gpm 9.9 gpm Overall Hydraulic Pump Flow 9.5 gpm 9.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves Optional, up to 2 1 (optional rear valve) ▶ Fluid CapacityFuel Tank Capacity 8.5 gal 8.1 gal Coolant Capacity Not Published 4.7 qt Crankcase Capacity 5.0 qt 5.7 qt Transmission / Hydraulic System Capacity 5.5 gal 3.83 gal Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2460 rpm None (no mid-PTO) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,535 lb 1,786 lb Hitch Lift Capacity (at 24”) 1,962 lb 1,400 lb Lift Control Type Position control valve Quarter inching valve ▶ Transmission & DrivetrainTransmission Type HST (3 ranges) Hydrostatic transmission, 3-range No. of Speeds HST (3 ranges) 3-range Max Travel Speed (Forward) 17.0 mph 11.9 mph Max Travel Speed (Reverse) 13.0 mph 9.5 mph Clutch Not Published Dry single plate Differential Lock & Limited Slip Options Standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS (sunshade optional) Steering Hydrostatic power steering Integral type power steering Brakes Multi-plate wet disk Wet disc type Seat Suspension & Adjustability Deluxe suspension seat (high back, designed to absorb shock) Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb 1,100 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 116.1 in 99.2 in (without 3-point hitch) Overall Width 53.7 in 53.7 in Wheelbase 66.7 in 66.8 in Ground Clearance 8.9 in 14.6 in Min. Turn Radius without Brakes 7.5 ft (with brake applied) 7.9 ft (with brake applied) Height to Top of ROPS 88.2 in 88.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 85.6 in Not Published ▶ WeightTractor Weight (Base) 2,191 lb 1,764 lb (farm tires); 1,786 lb (industrial tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 Not Published R1 Agricultural - Front 180/85D12 7-12 R1 Agricultural - Rear 320/85D16 12.4-16 R3 Turf - Front 24x8.5-14 Not Published R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front 23x8.5-12 or 25x8.5-14 Not Published R4 Industrial - Rear 14-17.5 or 15-19.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA545: 2-lever quick coupler, standard; Swift-Tach, optional Not Published Loader Model LA545 LA504 Loader Lift Height 87.6 in LA504: 82.6 in Loader Lift Capacity (Full Height) 1,100 lb LA504: 1,065 lb Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published
