▶ EngineEngine Manufacturer Kubota Kubota Engine Model V1505-CR-TE5-D40R5 Not Published Engine Type Turbocharged, direct injection, liquid-cooled diesel Indirect injection, liquid-cooled diesel No. of Cylinders 4 3 Displacement 91.4 in³ 111.4 in³ Rated Engine Speed 2700 rpm 2700 rpm Engine Power (Gross) 34.9 hp 35.7 hp PTO Power 28.7 hp F (2WD gear), DT (4WD gear): 30 hp; HST (4WD): 28.5 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 6 in paper filter (with dual element) Not Published Fuel System Direct injection Indirect injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Dual pump Not Published Implement Flow 5.4 gpm 6.3 gpm Steering Flow 4.1 gpm 3.8 gpm Total Hydraulic Flow 9.5 gpm 10.1 gpm (6.3 + 3.8, computed) Overall Hydraulic Pump Flow 9.5 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves Optional, up to 2 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 8.5 gal 9.0 gal Coolant Capacity Not Published Not Published Crankcase Capacity 5.0 qt Not Published Transmission / Hydraulic System Capacity 5.5 gal F (2WD): 7.1 gal; DT (4WD): 7.3 gal; HST (4WD): 6.2 gal Front Axle Fluid Capacity 4.8 qt 4.8 qt ▶ PTO & HitchPTO Type Independent F (2WD gear), DT (4WD gear): live-continuous running; HST (4WD): live-continuous with overrunning clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability 2460 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,535 lb 1,998 lb Hitch Lift Capacity (at 24”) 1,962 lb 1,435 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type HST (3 ranges) F (2WD gear), DT (4WD gear): sliding gear and constant mesh, 8F/4R; HST (4WD): hydrostatic transmission, 3-range No. of Speeds HST (3 ranges) F (2WD gear), DT (4WD gear): 8F/4R; HST (4WD): 3-range Max Travel Speed (Forward) 17.0 mph F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Max Travel Speed (Reverse) 13.0 mph F (2WD gear), DT (4WD gear): 4.7 mph; HST (4WD): 12.7 mph Clutch Not Published F (2WD gear), DT (4WD gear): dry-type, dual-stage; HST (4WD): dry-type, single-stage Differential Lock & Limited Slip Options Standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS (standard on all models) Steering Hydrostatic power steering Integral type power steering Brakes Multi-plate wet disk Wet disc type Seat Suspension & Adjustability Deluxe suspension seat (high back, designed to absorb shock) Not Published Front Axle Type Not Published 4WD: Bevel gear front axle Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 116.1 in F (2WD gear): 110.6 in; DT (4WD gear), HST (4WD): 106.5 in (without 3-point hitch) Overall Width 53.7 in 51.4 in Wheelbase 66.7 in 63.3 in Ground Clearance 8.9 in F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.4 in Min. Turn Radius without Brakes 7.5 ft (with brake applied) F (2WD gear): 7.9 ft; DT (4WD gear), HST (4WD): 8.2 ft (with brake applied) Height to Top of ROPS 88.2 in 85.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 85.6 in Not Published ▶ WeightTractor Weight (Base) 2,191 lb F (2WD gear): 2,403 lb; DT (4WD gear): 2,580 lb; HST (4WD): 2,600 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial, R14 AG standard; turf and industrial optional R1 Agricultural - Front 180/85D12 F (2WD gear): 5-15; DT (4WD gear), HST (4WD): 7-16 R1 Agricultural - Rear 320/85D16 11.2-24 R3 Turf - Front 24x8.5-14 25x8.50-14 (4WD) R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front 23x8.5-12 or 25x8.5-14 27x8.50-15 (4WD) R4 Industrial - Rear 14-17.5 or 15-19.5 15-19.5 R4 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System LA545: 2-lever quick coupler, standard; Swift-Tach, optional LA463: quick attach/detach loader (mounting pins and hose couplers from the seat); skid steer-type quick coupler optional Loader Model LA545 LA463 Loader Lift Height 87.6 in LA463: 95.3 in Loader Lift Capacity (Full Height) 1,100 lb LA463: 1,142 lb Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published
