▶ EngineEngine Manufacturer Kubota KIOTI Engine Model V1505-CR-TE5-D40R6 CK3520, CK3520H: 3H-TM4A; CK3520SE, CK3520SEH, CK3520SEH CAB: 3H-TM4B Engine Type Turbocharged, direct injection, liquid-cooled diesel 3-cylinder, in-line, liquid-cooled diesel No. of Cylinders 4 3 Displacement 91.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 34.9 hp 34.9 hp PTO Power 29.6 hp CK3520, CK3520SE: 30.9 hp; CK3520H, CK3520SEH, CK3520SEH CAB: 28.9 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Pressurized radiator Liquid-cooled Air Cleaner 6 in paper filter (with dual element) Dry element Fuel System Direct injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Dual pump Gear Implement Flow Not Published CK3520, CK3520H: 7.14 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 6.86 gpm Steering Flow Not Published CK3520, CK3520H: 4.59 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 4.46 gpm Total Hydraulic Flow 9.1 gpm CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Overall Hydraulic Pump Flow 9.1 gpm CK3520, CK3520H: 11.73 gpm; CK3520SE, CK3520SEH, CK3520SEH CAB: 11.33 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None CK3520, CK3520H: None; CK3520SE, CK3520SEH, CK3520SEH CAB: 2 No. of Optional Remote Valves Optional, up to 2 CK3520, CK3520H: 2 ▶ Fluid CapacityFuel Tank Capacity 8.5 gal 9.0 gal Coolant Capacity Not Published 0.89 gal Crankcase Capacity 5.0 qt 1.6 gal Transmission / Hydraulic System Capacity 5.5 gal 5.8 gal Front Axle Fluid Capacity 4.8 qt 1.6 gal ▶ PTO & HitchPTO Type Independent CK3520, CK3520H: Live; CK3520SE, CK3520SEH, CK3520SEH CAB: Independent PTO Rear 540 rpm 540 rpm (1-3/8 in, 6 splines) Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,348 lb 2,270 lb Hitch Lift Capacity (at 24”) 1,819 lb 1,631 lb Lift Control Type Position control valve Position control ▶ Transmission & DrivetrainTransmission Type Gear CK3520: Manual; CK3520H, CK3520SEH, CK3520SEH CAB: Hydrostatic; CK3520SE: Synchro shuttle No. of Speeds Not Published CK3520: 9F/3R; CK3520H, CK3520SEH, CK3520SEH CAB: Infinite, 3 range; CK3520SE: 12F/12R Max Travel Speed (Forward) 14.7 mph CK3520: 14.64 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 14.88 mph; CK3520SE: 15.53 mph Max Travel Speed (Reverse) 14.6 mph CK3520: 9.56 mph; CK3520H, CK3520SEH, CK3520SEH CAB: 10.41 mph; CK3520SE: 15.14 mph Clutch Dry type single stage CK3520: dry, dual-stage; CK3520H, CK3520SE: dry, single-stage; CK3520SEH, CK3520SEH CAB: n/a (hydrostatic) Differential Lock & Limited Slip Options Standard Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Multi-plate wet disk Wet multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD, manual engagement Front Axle Rating Not Published Not Published Drawbar Capacity 1,100 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 39.4 in 54.5 in Wheelbase 61.0 in 65.7 in Ground Clearance 12.8 in 13.4 in Min. Turn Radius without Brakes 7.5 ft (with brake applied) 107.5 in Height to Top of ROPS 84.0 in 92.9 in Height to Top of ROPS (folded) 56.7 in Not Published Height to Top of Cab Model Not Applicable n/a (ROPS model) Overall Length 98.2 in (without 3-point hitch, with R1 tires) 120.87 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,154 lb CK3520: 2,679 lb; CK3520H: 2,734 lb; CK3520SE: 2,906 lb; CK3520SEH: 2,921 lb; CK3520SEH CAB: 3,397 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural Front AG 7-16 (Turf 28x8.5-15/6, Industrial 27x8.5-15); Rear AG 11.2-24 (Turf 41x14-20/4, Industrial 15-19.5) R1 Agricultural - Front 6-14 7-16 R1 Agricultural - Rear 8.3-24 11.2-24 R3 Turf - Front Not Published 28x8.5-15/6 R3 Turf - Rear Not Published 41x14-20/4 R4 Industrial - Front Not Published 27x8.5-15 R4 Industrial - Rear Not Published 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model Not Published KL4030; KL4030C Loader Lift Height Not Published 98.4 in (KL4030 and KL4030C loaders) Loader Lift Capacity (Full Height) Not Published KL4030: 1,835 lb; KL4030C: 1,969 lb Loader Breakout Force Not Published KL4030: 3,464 lb; KL4030C: 2,989 lb ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Non-commercial: basic 24 months, powertrain 72 months, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
