▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3307-CR-TE4 V3307-CR-TE4 Engine Type Liquid-cooled, diesel, 4-cylinder Liquid-cooled, diesel, 4-cylinder No. of Cylinders 4 4 Displacement 203 in³ 203 in³ Rated Engine Speed 2400 rpm 2400 rpm Engine Power (Gross) 71.1 hp 65.4 hp PTO Power 60 hp 52 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual element (primary and secondary elements) Dual element (primary and secondary elements) Fuel System Common Rail System (CRS) Common Rail System (CRS) Alternator 130 A 130 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 16.7 gpm 16.7 gpm Steering Flow 6.3 gpm 6.3 gpm Total Hydraulic Flow 23.0 gpm (16.7 gpm implement + 6.3 gpm steering, computed) 23.0 gpm (16.7 gpm implement + 6.3 gpm steering, computed) Overall Hydraulic Pump Flow 23.0 gpm (16.7 + 6.3, computed) 23.0 gpm (16.7 + 6.3, computed) Hydraulic System Type Open Center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (SCD / FD) 2 (SCD / FD) No. of Optional Remote Valves Max. 3 Max. 3 ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 23.8 gal Coolant Capacity 10.6 qt 10.6 qt Crankcase Capacity 12.7 qt 12.7 qt Transmission / Hydraulic System Capacity 49.6 qt 49.6 qt Front Axle Fluid Capacity 5.8 qt (front differential case) plus 3.7 qt (front axle gear case) 5.8 qt (front differential case) plus 3.7 qt (front axle gear case) ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540/540E rpm 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch I / II I / II Hitch Lift Capacity 4,189 lb 4,189 lb Hitch Lift Capacity (at 24”) 3,307 lb 3,307 lb Lift Control Type Position, draft (top link sensing) & mixed control Position, draft (top link sensing) & mixed control ▶ Transmission & DrivetrainTransmission Type Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) No. of Speeds F12/R12 (option: F18/R18 with creep) F12/R12 (option: F18/R18 with creep) Max Travel Speed (Forward) 24.9 mph 24.9 mph Max Travel Speed (Reverse) 24.7 mph 24.7 mph Clutch Multiple wet disc Multiple wet disc Differential Lock & Limited Slip Options Front: limited-slip differential; Rear: mechanical differential lock Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Ultra Grand Cab II Ultra Grand Cab II Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet disc Hydraulic wet disc Seat Suspension & Adjustability Mechanical-suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air-suspension seat Mechanical-suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air-suspension seat Front Axle Type Bevel gear type (4WD) Bevel gear type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity 2,200 lb 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 75.6 in 75.6 in Wheelbase 84.1 in 84.1 in Ground Clearance 18.1 in (front axle crop clearance) 18.1 in (front axle crop clearance) Min. Turn Radius without Brakes 11.8 ft 11.8 ft Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 101 in 101 in Overall Length 144 in 144 in ▶ WeightTractor Weight (Base) 6,008 lb 6,008 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 320/70R24 front, 420/75R34 rear Standard: 320/70R24 front, 420/75R34 rear R1 Agricultural - Front 320/70R24 320/70R24 R1 Agricultural - Rear 420/75R34 420/75R34 R3 Turf - Front 9.50-24 9.50-24 R3 Turf - Rear 18.4-26 18.4-26 R4 Industrial - Front 14-17.5 14-17.5 R4 Industrial - Rear 16.9-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1154A: 2-Lever Quick Coupler LA1154A: 2-Lever Quick Coupler Loader Model LA1154A LA1154A Loader Lift Height LA1154A: Height position: 133.0 in; Power position: 117.6 in LA1154A: Height position: 133.0 in; Power position: 117.6 in Loader Lift Capacity (Full Height) LA1154A: Height position: 2,674 lb; Power position: 2,928 lb LA1154A: Height position: 2,674 lb; Power position: 2,928 lb Loader Breakout Force LA1154A: Height position: 4,079 lbf; Power position: 5,128 lbf LA1154A: Height position: 4,079 lbf; Power position: 5,128 lbf ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
