▶ EngineEngine Manufacturer Kubota John Deere Engine Model V3800CR-TIEF4 PowerTech 4045 (4.5L) PWL Engine Type 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR 4-cylinder, turbocharged and aftercooled diesel, electronic fuel control No. of Cylinders 4 4 Displacement 230 in³ 276 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) 92.5 hp 90 hp PTO Power 76 hp 76.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element, 8 in diameter, with pre-cleaner Dry type with safety element Fuel System Common rail direct injection High pressure common rail, electronic fuel control Alternator 80 A OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Gear pump Tandem gear pump, two engine-mounted pumps Implement Flow 17.0 gpm 15.9 gpm Steering Flow 6.1 gpm 6.6 gpm Total Hydraulic Flow 23.1 gpm 22.5 gpm Overall Hydraulic Pump Flow 23.1 gpm 22.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 17.0 gpm Not Published No. of Standard Remote Valves 2 standard (3 maximum) 2 rear; 0 mid No. of Optional Remote Valves Not Published 3 rear; up to 3 mid ▶ Fluid CapacityFuel Tank Capacity 27.7 gal 25 gal (open operator station); 30 gal (cab) Coolant Capacity 11 qt 2.5 gal (open operator station); 3 gal (cab) Crankcase Capacity 11.3 qt 3.2 gal Transmission / Hydraulic System Capacity 63.4 qt 11.5 gal Front Axle Fluid Capacity 6.3 qt (differential) plus 3.7 qt (each bevel gear case) 1.3 gal (MFWD differential housing); 0.74 qt (each wheel hub) ▶ PTO & HitchPTO Type Live-independent PTO, electro-hydraulic clutch with brake Independent, electro-hydraulic engagement, wet PTO clutch PTO Rear 540 rpm (540/540E optional) 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category 2, convertible to Category 1 Hitch Lift Capacity 7,055 lb 5,159 lb (maximum lift force at hitch ball); 3,846 lb throughout lift range Hitch Lift Capacity (at 24”) 4,630 lb 4,630 lb (electrohydraulic hitch) Lift Control Type Position, draft (top link sensing) and mixed control Electro-hydraulic hitch with electronic quick raise and lower (premium cab); top-link draft sensing ▶ Transmission & DrivetrainTransmission Type Fully synchronized main gear shift with electro-hydraulic shuttle PowrReverser 12F/12R standard; PowrReverser Hi-Lo 24F/12R optional No. of Speeds 8 forward, 8 reverse 12 forward, 12 reverse (standard); 24 forward, 12 reverse (Hi-Lo) Max Travel Speed (Forward) 19.2 mph 21.7 mph (electronically limited) Max Travel Speed (Reverse) Not Published 21.7 mph (electronically limited) Clutch Multiple wet disc Wet Differential Lock & Limited Slip Options Front: limited-slip differential; Rear: mechanical differential lock Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS (open operator station); standard or premium cab; MFWD Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet disc Hydraulic wet disc, self-equalizing and self-adjusting, dual-stage Seat Suspension & Adjustability Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Mechanical seat standard; air-suspension seat optional for cab Front Axle Type Bevel gear type with 55 degree turning angle (4WD) MFWD Front Axle Rating 5,730 lb 6,615 lb Drawbar Capacity 3,300 lb 2,755 lb (standard drawbar, 9.8 in extended); 2,425 lb (standard drawbar, 350 and 15.7 in extended); 3,195 lb (heavy-duty drawbar, 9.8 in extended); 2,645 lb (heavy-duty drawbar, 350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width 78.3 in 83.6 in (minimum, 16.9-30 R1 tires); 85.1 in (minimum, 18.4-30 R1 tires) Wheelbase 88.6 in 92.5 in Ground Clearance 17.7 in (minimum, drawbar bracket) 17 in (front axle) Min. Turn Radius without Brakes 13.8 ft 11.6 ft (MFWD) Height to Top of ROPS Not Published 101.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in 102.4 in Overall Length 155.9 in 159.13 in ▶ WeightTractor Weight (Base) 6,900 lb 7,275 lb (MFWD open operator station, shipping weight); 8,150 lb (MFWD cab, shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 18.4-30 R1 bias rear standard; 16.9-30 R1 also listed R1 Agricultural - Front 11.2-24 12.4-24 R1 Agricultural - Rear 18.4-30 18.4-30 R1 bias R3 Turf - Front 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) Not Published R3 Turf - Rear 18.4-26 R3 or 19.5L-24 R3 Not Published R4 Industrial - Front 9.5L-15 F2 (rib front paired with the R4 rear) Not Published R4 Industrial - Rear 19.5L-24 R4 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional Quick attach option with integrated parking stand Loader Model LA1854 520M (NSL and MSL); 540M (NSL) Loader Lift Height 145.7 in (height position); 131.9 in (power position) 520M MSL: 132.0 in Loader Lift Capacity (Full Height) 3,990 lb (height position); 4,144 lb (power position) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force LA1854: 5,501 lb at bucket pivot pin (height position); 6,470 lb at bucket pivot pin (power position) 520M NSL: 4,511 lbf; 520M MSL: 4,793 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours Powertrain 5 years or 2,000 hours, as sold new
