▶ EngineEngine Manufacturer Kubota Kubota Engine Model F2803 V2403-CR-E4-GL5 Engine Type Diesel, 5-cylinder, liquid-cooled Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 5 4 Displacement 167.5 in³ 148.5 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 61.6 hp 62 hp PTO Power 52 hp 53 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Two paper elements Dry paper, dual element Fuel System Indirect injection Electronic Common Rail System (CRS) Alternator Not Published 45 A, 12 V ▶ HydraulicsPump Type Not Published Tandem pump - gear type Implement Flow 11 gpm 9.4 gpm Steering Flow Not Published 4.7 gpm Total Hydraulic Flow Not Published 14.1 gpm Overall Hydraulic Pump Flow Not Published 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 to 3 Not Published No. of Optional Remote Valves Not Published Optional, up to 3 (double-acting valve or float detent valve options, any position) ▶ Fluid CapacityFuel Tank Capacity ROPS: 17.2 gal; Cab: 25.1 gal 13.5 gal Coolant Capacity 8.5 qt 8.7 qt Crankcase Capacity 8.5 qt 9.9 qt Transmission / Hydraulic System Capacity 13.7 gal 11.9 gal Front Axle Fluid Capacity Not Published 8.9 qt ▶ PTO & HitchPTO Type Independent Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2400 engine rpm Mid-PTO Availability Not Published Optional Category, 3-Point Hitch Category II/I SAE Category I & II Hitch Lift Capacity Not Published 3,858 lb Hitch Lift Capacity (at 24”) 2840 lb (as tested; advertised 3310 lb) 2,976 lb Lift Control Type Position control and top-link draft sensing Position control ▶ Transmission & DrivetrainTransmission Type 8-speed synchronized shuttle Hydrostatic transmission No. of Speeds 8F/8R 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) Not Published 16.8 mph Max Travel Speed (Reverse) Not Published 15.2 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet disc type, mechanically activated Seat Suspension & Adjustability Not Published Suspension seat with fore/aft travel adjustment, suspension adjust knob, backrest tilt adjustment, swivel and arm rest Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD ROPS: 137.6 in; 4WD ROPS: 134.1 in; 2WD cab: 140.6 in; 4WD cab: 137 in 135.0 in Overall Width 72.8 in (minimum) 67.3 in Wheelbase ROPS: 78.7 in; Cab: 81.7 in 75.4 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes Not Published 9.2 ft (with brake applied) Height to Top of ROPS 93.5 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 99.0 in Not Applicable ▶ WeightTractor Weight (Base) 2WD ROPS: 3858 lb; 4WD ROPS: 4078 lb 3,990 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD: 7.50-16 front; 4WD: 9.5-22 front; 16.9-28 rear Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 2WD: 7.50-16; 4WD: 9.5-22 9.5-16 R1 Agricultural - Rear 16.9-28 14.9-26; 13.6-28 R3 Turf - Front Not Published 29X12.50-15 R3 Turf - Rear Not Published 44X18-20 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Model LA1002 LA1055 Loader Lift Height LA1002: 115.6 in 112.7 in Loader Lift Capacity (Full Height) LA1002: 2579 lb 2361 lb Loader Breakout Force LA1002: 3330 lbf 3171 lbf (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
