▶ EngineEngine Manufacturer Kubota Kubota Engine Model F2803-EA V2403-CR-TIE5 Engine Type Vertical, water-cooled, 4-cycle diesel, 5-cylinder Turbocharged and intercooled, common-rail, water-cooled 4-cycle diesel No. of Cylinders 5 4 Displacement 167.6 in³ 148.5 in³ Rated Engine Speed 2800 rpm 2300 rpm Engine Power (Gross) 61.6 hp 60 hp PTO Power 52 hp 53 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Primary element and secondary (safety) element Not Published Fuel System Indirect injection Common rail system (CRS), electronically controlled fuel injection Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11 gpm 9.83 gpm Steering Flow Not Published Not Published Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Not Published Up to 3 (optional) ▶ Fluid CapacityFuel Tank Capacity ROPS: 17.2 gal; Cab: 25.1 gal Not Published Coolant Capacity 7.7 qt Not Published Crankcase Capacity 8.5 qt Not Published Transmission / Hydraulic System Capacity ROPS: 42.3 qt; Cab: 45.4 qt Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category I and II Hitch Lift Capacity Not Published 3,858 lb Hitch Lift Capacity (at 24”) 3,307 lb 2,976 lb Lift Control Type Position, draft and mix control Not Published ▶ Transmission & DrivetrainTransmission Type 8 forward and 8 reverse, fully synchronized main shift Hydrostatic transmission, 3-range, with Hydro-Dual Speed (H-DS) No. of Speeds 8F/8R 3-range Max Travel Speed (Forward) Not Published 18.5 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Open ROPS or enclosed cab Steering Power steering Hydrostatic power steering Brakes Wet disc Wet disc type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 72.8 in (minimum) 67.3 in Wheelbase ROPS: 78.7 in; Cab: 81.7 in 81.3 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes Not Published 9.5 ft (with brake applied) Height to Top of ROPS 93.5 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 99.0 in 93.3 in Overall Length 2WD ROPS: 137.6 in; 4WD ROPS: 134.1 in; 2WD cab: 140.6 in; 4WD cab: 137.1 in 133.9 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2WD ROPS: 3,858 lb; 4WD ROPS: 4,078 lb 4,387 lb (ROPS); 4,762 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD: 7.5-16 front; 4WD: 9.5-22 front; 16.9-28 rear Standard: 9.5-16 front, 14.9-26 rear R1 Agricultural - Front 2WD: 7.50-16; 4WD: 9.5-22 9.5-16 R1 Agricultural - Rear 16.9-28 14.9-26 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA1056, LM1056: toolless loader removal with integrated parking stands; optional third-function valve Loader Model LA1002 LA1056; LM1056 Loader Lift Height LA1002: 115.6 in LA1056: 117 in; LM1056: 117 in Loader Lift Capacity (Full Height) LA1002: 2,579 lb (at pivot pin) LA1056: 2,427 lb; LM1056: 2,471 lb Loader Breakout Force LA1002: 3,330 lbf LA1056: 4,069 lbf; LM1056: 4,061 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
