▶ EngineEngine Manufacturer Kubota John Deere Engine Model V3800-TI-CRS PowerTech 4045 PWL Engine Type 4-cylinder, turbocharged and intercooled, common-rail, liquid-cooled diesel Diesel, turbocharged, air-to-air aftercooled No. of Cylinders 4 4 Displacement 230 in³ 276 in³ Rated Engine Speed 2600 rpm 2200 rpm Engine Power (Gross) 114.1 hp 113.9 hp PTO Power 92 hp 100 hp @ 100 rpm Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, pressurized radiator, recovery tank Liquid-cooled (Cool-Gard II coolant) Air Cleaner 8 in dry, dual element Dry air cleaner, primary and secondary elements Fuel System Common rail direct injection High pressure common rail (HPCR); electronic fuel control Alternator 130 A, 12 V OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V ▶ HydraulicsPump Type Gear pumps Tandem gear pump Implement Flow 18.7 gpm 18.4 gpm Steering Flow 16.0 gpm 6.3 gpm Total Hydraulic Flow 34.7 gpm (18.7 + 16.0, computed) 24.7 gpm Overall Hydraulic Pump Flow Not Published 24.7 gpm Hydraulic System Type Pressure compensated, fixed displacement Open center Rear Remote Hydraulic Flow 18.7 gpm Not Published No. of Standard Remote Valves 2 (with built-in flow control) 2 (rear, Dual SCV) No. of Optional Remote Valves 3rd and 4th optional (4 max) 3 rear valves total (3rd rear SCV optional); up to 3 mid SCVs (XI, XII, XIII) for loader functions ▶ Fluid CapacityFuel Tank Capacity 50.2 gal OOS: 37.2 gal; Cab: 44.9 gal Coolant Capacity 11.3 qt OOS: 5.2 gal; Cab: 5.8 gal Crankcase Capacity 11.3 qt 3.4 gal Transmission / Hydraulic System Capacity 17.2 gal 10.4 gal Front Axle Fluid Capacity 7.2 qt (differential) plus 3.8 qt per bevel gear case Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal ▶ PTO & HitchPTO Type Live, independent PTO, hydraulically operated wet clutch with PTO brake Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional PTO Rear 540/1000 rpm 540/540E rpm standard; 1000 rpm optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (convertible to I) Hitch Lift Capacity 8,598 lb 5,305 lb standard; 6,114 lb optional Hitch Lift Capacity (at 24”) 6,834 lb (optional 9,447 lb) 5,159 lb standard; 5,954 lb optional Lift Control Type Electronic draft control, lower-link sensing; left fender-mounted hitch switch standard Mechanical or electrohydraulic; lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type 24F/24R powershift (8-speed main, 3-speed mechanical range, clutch button, microprocessor-controlled electro-hydraulic shuttle); 32F/32R optional with creep PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo; PowrQuad PLUS 16F/16R and Powr8 32F/16R also offered No. of Speeds 24F/24R (32F/32R with optional creep) 16F/16R standard (PowrReverser); 32F/16R optional (PowrReverser Hi-Lo); 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) Max Travel Speed (Forward) 23.4 mph 16F/16R PowrReverser, top gear (D-4), 40K config: 21.72 mph (480/70R28 Mitas rear tires, 2200 rpm) Max Travel Speed (Reverse) 22.33 mph (with 18.4R38 tires, at rated rpm) 16F/16R PowrReverser, top gear (D-4), 40K config: 23.94 mph (480/70R28 Mitas rear tires, 2200 rpm) Clutch Multiple wet disc, electro-hydraulically operated, 5.2 in Wet Differential Lock & Limited Slip Options Electro-hydraulic front differential lock; rear differential lock standard Electro-hydraulic rear differential lock, engage on the go ▶ Chassis, Steering & ControlsFrame Type Certified ROPS cab standard Cast iron mid-frame Steering Hydrostatic power steering Not Published Brakes Hydraulically operated wet disc brakes with automatic front axle engagement (4WD) Not Published Seat Suspension & Adjustability Air-suspension seat, swivel, reclining, fully adjustable (height, weight, fore-aft), armrests, retractable seat belt OOS: isolated mechanical seat (fore/aft, weight, and lumbar adjustment); Cab: mechanical suspension seat standard, air suspension seat optional; adjustable weight range 88-330 lb Front Axle Type 4WD, bevel-gear type, on-the-go electro-hydraulic engagement, electro-hydraulic front differential lock MFWD Front Axle Rating 6,610 lb at 62.2 in tread (9,700 lb with loader) 6,613 lb (MFWD, max permissible front axle load) Drawbar Capacity Not Published Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb ▶ Dimensions & ManeuverabilityOverall Width 82.7 in Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Wheelbase 95.9 in 92.5 in Ground Clearance 19.5 in (crop clearance) Not Published Min. Turn Radius without Brakes 13.1 ft (with Bi-Speed turn, 4WD on) Not Published Height to Top of ROPS Not Published 102.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.8 in 102.9 in Overall Length 165.4 in 149.5 in ▶ WeightTractor Weight (Base) 9,788 lb (with standard tire) MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (shipping weight, less weights; 2WD not offered) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 13.6 R24 front, 18.4 R34 rear (R1 options 12.4-24, 13.6-24 front; 16.9-34, 18.4R30, 18.4-34 rear) Not Published R1 Agricultural - Front 13.6 R24 12.4R24 (320/85R24) R1W Radial R1 Agricultural - Rear 18.4 R34 18.4R30 (460/85R30) R1W Radial R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA1955: 2-lever quick coupler or Euro quick coupler; single-lever hydraulic quick coupler; quick attach/detach loader with boom stands, two mounting pins Not Published Loader Model LA1955 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) Loader Lift Height LA1955 (height position): 145.7 in; LA1955 (power position): 132.7 in 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in Loader Lift Capacity (Full Height) LA1955 (height position): 4,178 lb at pivot pin; LA1955 (power position): 4,299 lb at pivot pin 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) Loader Breakout Force LA1955 (height position): 5,589 lbf at pivot pin; LA1955 (power position): 6,576 lbf at pivot pin 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
