▶ EngineEngine Manufacturer Kubota KIOTI Engine Model V3800-TI-CRS 4J243TA-TP5B Engine Type 4-cylinder, turbocharged and intercooled, common-rail, liquid-cooled diesel 4-cylinder, in-line vertical, water-cooled, turbocharged and intercooled CRDI diesel (4J243TA-TP5B) No. of Cylinders 4 4 Displacement 230 in³ 233.9 in³ Rated Engine Speed 2600 rpm 2200 rpm Engine Power (Gross) 114.1 hp 115.3 hp PTO Power 92 hp 83.9 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled, pressurized radiator, recovery tank Water-cooled Air Cleaner 8 in dry, dual element Dry element with evacuator valve Fuel System Common rail direct injection CRDI Alternator 130 A, 12 V Not Published ▶ HydraulicsPump Type Gear pumps Gear Implement Flow 18.7 gpm 19.8 gpm Steering Flow 16.0 gpm 12.2 gpm Total Hydraulic Flow 34.7 gpm (18.7 + 16.0, computed) 32 gpm Overall Hydraulic Pump Flow Not Published 32 gpm Hydraulic System Type Pressure compensated, fixed displacement Open Center Rear Remote Hydraulic Flow 18.7 gpm Not Published No. of Standard Remote Valves 2 (with built-in flow control) 3 No. of Optional Remote Valves 3rd and 4th optional (4 max) 4th remote valve ▶ Fluid CapacityFuel Tank Capacity 50.2 gal 47.6 gal Coolant Capacity 11.3 qt 4.7 gal Crankcase Capacity 11.3 qt 3.9 gal Transmission / Hydraulic System Capacity 17.2 gal 20.34 gal Front Axle Fluid Capacity 7.2 qt (differential) plus 3.8 qt per bevel gear case 2.6 gal ▶ PTO & HitchPTO Type Live, independent PTO, hydraulically operated wet clutch with PTO brake Independent PTO Rear 540/1000 rpm 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 8,598 lb 8,079 lb Hitch Lift Capacity (at 24”) 6,834 lb (optional 9,447 lb) 8,002 lb Lift Control Type Electronic draft control, lower-link sensing; left fender-mounted hitch switch standard Electronic control ▶ Transmission & DrivetrainTransmission Type 24F/24R powershift (8-speed main, 3-speed mechanical range, clutch button, microprocessor-controlled electro-hydraulic shuttle); 32F/32R optional with creep Power Shuttle w/ Hi-Lo Shift No. of Speeds 24F/24R (32F/32R with optional creep) 24 forward / 24 reverse Max Travel Speed (Forward) 23.4 mph 23.83 mph Max Travel Speed (Reverse) 22.33 mph (with 18.4R38 tires, at rated rpm) 23.67 mph Clutch Multiple wet disc, electro-hydraulically operated, 5.2 in Wet Multi Disc Differential Lock & Limited Slip Options Electro-hydraulic front differential lock; rear differential lock standard Mechanical rear differential lock (standard); front limited-slip differential ▶ Chassis, Steering & ControlsFrame Type Certified ROPS cab standard Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Hydraulically operated wet disc brakes with automatic front axle engagement (4WD) Wet Disc Seat Suspension & Adjustability Air-suspension seat, swivel, reclining, fully adjustable (height, weight, fore-aft), armrests, retractable seat belt Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Front Axle Type 4WD, bevel-gear type, on-the-go electro-hydraulic engagement, electro-hydraulic front differential lock 4WD, outboard planetary drives, limited-slip differential Front Axle Rating 6,610 lb at 62.2 in tread (9,700 lb with loader) Not Published Drawbar Capacity Not Published Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb ▶ Dimensions & ManeuverabilityOverall Width 82.7 in 88.6 in Wheelbase 95.9 in 94.9 in Ground Clearance 19.5 in (crop clearance) 18.9 in Min. Turn Radius without Brakes 13.1 ft (with Bi-Speed turn, 4WD on) 12.7 ft (with brake applied) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.8 in 111.9 in Overall Length 165.4 in 170.8 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 9,788 lb (with standard tire) 10,230 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 13.6 R24 front, 18.4 R34 rear (R1 options 12.4-24, 13.6-24 front; 16.9-34, 18.4R30, 18.4-34 rear) R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) R1 Agricultural - Front 13.6 R24 13.6-24 R1 Agricultural - Rear 18.4 R34 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA1955: 2-lever quick coupler or Euro quick coupler; single-lever hydraulic quick coupler; quick attach/detach loader with boom stands, two mounting pins KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Loader Model LA1955 KL1155 Loader Lift Height LA1955 (height position): 145.7 in; LA1955 (power position): 132.7 in KL1155: 150.6 in (to pivot pin) Loader Lift Capacity (Full Height) LA1955 (height position): 4,178 lb at pivot pin; LA1955 (power position): 4,299 lb at pivot pin KL1155: 4,216 lb (at pivot pins) Loader Breakout Force LA1955 (height position): 5,589 lbf at pivot pin; LA1955 (power position): 6,576 lbf at pivot pin KL1155: 8,554 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage Not Published Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 48 months, unlimited hours, HX series
