▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3307-DI F2803-ELA Engine Type 4-cylinder inline, direct injected diesel Vertical, water-cooled, 4-cycle diesel, 5-cylinder No. of Cylinders 4 5 Displacement 203 in³ 167.6 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) Not Published 54 hp PTO Power 55 hp 45 hp Engine Emissions Constraints Tier 2 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner 8 in dry, dual element Dual dry elements Fuel System Direct injection Not Published Alternator ROPS: 45 A, 12 V; Cab: 60 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11.0 gpm Not Published Steering Flow 6.1 gpm Not Published Total Hydraulic Flow 17.1 gpm (11.0 + 6.1, computed) 17.1 gpm Overall Hydraulic Pump Flow 17.1 gpm (11.0 + 6.1, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.0 gpm Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2nd and 3rd optional Not Published ▶ Fluid CapacityFuel Tank Capacity ROPS: 18.5 gal; Cab: 29.1 gal ROPS: 17.2 gal; Cab: 25.1 gal Coolant Capacity 8.5 qt 7.7 qt Crankcase Capacity 11.6 qt 8.5 qt Transmission / Hydraulic System Capacity 59.2 qt Not Published Front Axle Fluid Capacity Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side Not Published ▶ PTO & HitchPTO Type Live, independent PTO, hydraulically operated wet clutch with PTO brake Live PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category II/I Hitch Lift Capacity 4,189 lb 4,200 lb Hitch Lift Capacity (at 24”) 3,307 lb 3,307 lb Lift Control Type Position, draft (top link sensing) and mix control Position, draft and mix control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models Synchronized shuttle, 8F/8R (12F/12R with creeper) No. of Speeds 8F/8R (12F/12R with optional creep) 8F/8R (12F/12R with creeper) Max Travel Speed (Forward) 17.8 mph Not Published Max Travel Speed (Reverse) 18.0 mph Not Published Clutch Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Not Published Differential Lock & Limited Slip Options Rear differential lock (bevel gears) Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Multiple wet disc, mechanical Mechanical wet disc Seat Suspension & Adjustability Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Not Published Front Axle Type 4WD: bevel-gear type, on-the-go engagement Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 2,200 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 73.2 in 67.2 in (minimum) Wheelbase 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in ROPS: 78.7 in; Cab: 81.7 in Ground Clearance 15.4 in 16.9 in Min. Turn Radius without Brakes 2WD: 11.2 ft; 4WD: 11.8 ft Not Published Height to Top of ROPS 96.9 in 93.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 99.8 in 98.1 in Overall Length 2WD: 140.4 in; 4WD: 135.6 in 2WD ROPS: 137.6 in; 4WD ROPS: 134.1 in; 2WD cab: 140.6 in; 4WD cab: 137.1 in ▶ WeightTractor Weight (Base) 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb 2WD ROPS: 3,748 lb; 4WD ROPS: 3,968 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear Standard: 6.5-16 front (2WD), 9.5-22 front (4WD), 14.9-28 rear R1 Agricultural - Front 2WD: 7.5-16; 4WD: 9.5-24 8.3-24 R1 Agricultural - Rear 16.9-28 14.9-28 R3 Turf - Front 2WD: 29x12.5-15 or 27x9.5-15 2WD: 9.00-10; 4WD: 29x12.5-15 R3 Turf - Rear 2WD: 21.5L-16.1 or 16.9-24 21.5L-16.1 R3 R4 Industrial - Front 12.5/80-18 (4WD) 12.5/80-18 R4 R4 Industrial - Rear 16.9-24 (4WD) 16.9-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System LA1153: two-lever quick coupler Not Published Loader Model LA1153 LA1002 Loader Lift Height LA1153 height position: 132.7 in; LA1153 power position: 117.2 in LA1002: 115.6 in Loader Lift Capacity (Full Height) Not Published LA1002: 2,579 lb (at pivot pin) Loader Breakout Force Not Published LA1002: 3,330 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
