Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
KubotaM6060
No photo
—
BobcatUT6566
Comparison loaded for 2 tractors.
Spec
KubotaM6060
BobcatUT6566
PTO Power
56.0 hp (41.7 kW)
51.1 hp (38.1 kW)
Alternator
ROPS: 12 V, 45 A; CAB: 12 V, 60 A
Not Published
Air Cleaner
Not Published
Not Published
Engine Type
Liquid-cooled, diesel, 4-cylinder, Turbocharged
Diesel
Fuel System
Common Rail System (CRS)
Not Published
Displacement
203.3 (3331)
148.6 in³ (2,435 cc)
No. of Cylinders
4
4
Rated Engine Speed
2400 rpm
2,600 rpm
Cooling System Type
Liquid-cooled
Not Published
Engine Manufacturer
Kubota
Daedong (4HT-TP4A)
Engine Emissions Constraints
Tier IV EPA emission regulations; CRS with EGR + DPF muffler
Tier 4/Stage 5
Engine Power (Gross vs. Net HP)
Gross: 66.4 hp (49.5 kW)
66.4 hp (49.5 kW) (Gross)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Published
Not Published
Pump Type
Gear
Not Published
Steering Flow
23.1 L/min (6.1 gpm)
26.1 L/min (6.9 gpm)
Implement Flow
41.6 L/min (11.0 gpm)
41.6 L/min (11.0 gpm)
Total Hydraulic Flow
64.7 L/min (17.1 gpm)
67.7 L/min (17.9 gpm)
Hydraulic System Type
Open Center
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
64.7 L/min (17.1 gpm)
67.7 L/min (17.9 gpm)
No. of Optional Remote Valves
2nd, 3rd (optional)
2
No. of Standard Remote Valves
1 (SCD)
1
R3 Turf - Rear
Not Published
Not Published
R3 Turf - Front
Not Published
Not Published
Tire Size & Options
Standard tire size
Industrial (Ag, Multi-Use)
R4 Industrial - Rear
Not Published
18.4-24 (16.9-30, 480/80R26)
R4 Industrial - Front
Not Published
12.5/80-18 (9.5-24, 340/80R18)
R1 Agricultural - Rear
16.9-28/14.9-28
Not Published
R1 Agricultural - Front
HFC (2WD): 9.5L-15; HD/HDC (4WD): 9.5-24
Not Published
PTO Rear
540 rpm (540/540E optional)
540/540E rpm
PTO Type
Live-independent PTO, electro-hydraulic clutch with brake
Independent
Lift Control Type
Position, Draft (Top Link Sensing) & Mixed Control
Position with Draft Control
Hitch Lift Capacity
Not Published
Not Published
Mid-PTO Availability
Not Published
Not Applicable
Category, 3-Point Hitch
I / II
Category 2
Hitch Lift Capacity (at 24”)
3307 lbs (1500 kg)
3,594 lb (1,630 kg) @ 24 in behind lift point
Rear 3-Point Hitch Lift Capacity
Not Published
Not Published
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
ROPS: 18.5 gal (70 L); CAB: 23.8 gal (90 L)
25.1 gal (95.0 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
Height position: 132.7 in (3370 mm); Power position: 117.2 in (2977 mm)
129.0 in (3,276 mm)
Loader Breakout Force
Not Published
Not Published
Price for Backhoe Option
Not Applicable
Not Published
Price for Mid-Mount Mower
Not Published
Not Applicable
Quick Attach Loader System
LA1154A: 2-Lever Quick Coupler
Bob-Tach
Loader Lift Capacity (Full Height)
Height position: 2469 lb (1120 kg); Power position: 2928 lb (1328 kg)
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
