▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3307-DI V2403-CR-TIE5 Engine Type 4-cylinder inline, direct injected diesel Turbocharged and intercooled, common-rail, water-cooled 4-cycle diesel No. of Cylinders 4 4 Displacement 203 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) Not Published 60 hp PTO Power 62 hp 53 hp Engine Emissions Constraints Tier 2 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner 8 in dry, dual element Not Published Fuel System Direct injection Common rail system (CRS), electronically controlled fuel injection Alternator ROPS: 45 A, 12 V; Cab: 60 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11.0 gpm 9.83 gpm Steering Flow 6.1 gpm Not Published Total Hydraulic Flow 17.1 gpm (11.0 + 6.1, computed) Not Published Overall Hydraulic Pump Flow 17.1 gpm (11.0 + 6.1, computed) Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow 11.0 gpm Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves 2nd and 3rd optional Up to 3 (optional) ▶ Fluid CapacityFuel Tank Capacity ROPS: 18.5 gal; Cab: 29.1 gal Not Published Coolant Capacity 8.5 qt Not Published Crankcase Capacity 11.6 qt Not Published Transmission / Hydraulic System Capacity 59.2 qt Not Published Front Axle Fluid Capacity Front differential case: 5.8 qt; front axle gear case: 3.7 qt Not Published ▶ PTO & HitchPTO Type Live, independent PTO, hydraulically operated wet clutch with PTO brake Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity 4,189 lb 3,858 lb Hitch Lift Capacity (at 24”) 3,307 lb 2,976 lb Lift Control Type Position, draft (top link sensing) and mix control Not Published ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models Hydrostatic transmission, 3-range, with Hydro-Dual Speed (H-DS) No. of Speeds 8F/8R (12F/12R with optional creep) 3-range Max Travel Speed (Forward) 18.5 mph 18.5 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Not Published Differential Lock & Limited Slip Options Rear differential lock (bevel gears) Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS (canopy optional); Ultra Grand Cab optional Open ROPS or enclosed cab Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanically operated wet disc brakes Wet disc type Seat Suspension & Adjustability Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Not Published Front Axle Type 4WD: bevel-gear type, on-the-go engagement Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 2,200 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 73.2 in 67.3 in Wheelbase 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in 81.3 in Ground Clearance 16.3 in 15.4 in Min. Turn Radius without Brakes 2WD: 11.2 ft; 4WD: 11.8 ft 9.5 ft (with brake applied) Height to Top of ROPS 97.2 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in 93.3 in Overall Length 2WD: 140.4 in; 4WD: 135.6 in 133.9 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2WD: 4,475 lb; 4WD: 4,608 lb 4,387 lb (ROPS); 4,762 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 7.5-16 (2WD) or 9.5-24 (4WD) front, 16.9-30 rear Standard: 9.5-16 front, 14.9-26 rear R1 Agricultural - Front 2WD: 7.5-16; 4WD: 9.5-24 9.5-16 R1 Agricultural - Rear 16.9-30 14.9-26 R3 Turf - Front 29x12.5-15 or 27x9.5-15 Not Published R3 Turf - Rear 18.4-26 or 21.5L-16.1 Not Published R4 Industrial - Front 14-17.5L (4WD) Not Published R4 Industrial - Rear 16.9-24 (4WD) Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA1153: two-lever quick coupler LA1056, LM1056: toolless loader removal with integrated parking stands; optional third-function valve Loader Model LA1153 LA1056; LM1056 Loader Lift Height LA1153 height position: 132.7 in; LA1153 power position: 117.2 in LA1056: 117 in; LM1056: 117 in Loader Lift Capacity (Full Height) Not Published LA1056: 2,427 lb; LM1056: 2,471 lb Loader Breakout Force Not Published LA1056: 4,069 lbf; LM1056: 4,061 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
