▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3307-DI V3800CR-TIEF4 Engine Type 4-cylinder inline, direct injected diesel 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR No. of Cylinders 4 4 Displacement 203 in³ 230 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) Not Published 105.6 hp PTO Power 62 hp 89 hp Engine Emissions Constraints Tier 2 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner 8 in dry, dual element Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Direct injection Common rail direct injection Alternator ROPS: 45 A, 12 V; Cab: 60 A, 12 V 60 A ▶ HydraulicsPump Type Not Published Gear pump Implement Flow 11.0 gpm 15.7 gpm Steering Flow 6.1 gpm 5.4 gpm Total Hydraulic Flow 17.1 gpm (11.0 + 6.1, computed) 21.3 gpm Overall Hydraulic Pump Flow 17.1 gpm (11.0 + 6.1, computed) 21.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.0 gpm 15.7 gpm No. of Standard Remote Valves 1 2 (max 3) No. of Optional Remote Valves 2nd and 3rd optional 1 (3 maximum) ▶ Fluid CapacityFuel Tank Capacity ROPS: 18.5 gal; Cab: 29.1 gal 27.7 gal Coolant Capacity 8.5 qt 11 qt Crankcase Capacity 11.6 qt 11.3 qt Transmission / Hydraulic System Capacity 59.2 qt 63.4 qt Front Axle Fluid Capacity Front differential case: 5.8 qt; front axle gear case: 3.7 qt 6.3 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Live, independent PTO, hydraulically operated wet clutch with PTO brake Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category II Hitch Lift Capacity 4,189 lb 7,055 lb (8,600 lb optional) Hitch Lift Capacity (at 24”) 3,307 lb 5,181 lb Lift Control Type Position, draft (top link sensing) and mix control Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models Fully synchronized main gear shift with electro-hydraulic shuttle No. of Speeds 8F/8R (12F/12R with optional creep) 8 forward, 8 reverse Max Travel Speed (Forward) 18.5 mph 18.6 mph Max Travel Speed (Reverse) Not Published 18.4 mph Clutch Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock (bevel gears) Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS (canopy optional); Ultra Grand Cab optional Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanically operated wet disc brakes Hydraulic wet disc Seat Suspension & Adjustability Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Front Axle Type 4WD: bevel-gear type, on-the-go engagement Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5,730 lb Drawbar Capacity 2,200 lb 3,300 lb ▶ Dimensions & ManeuverabilityOverall Width 73.2 in 79.1 in Wheelbase 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in 88.6 in Ground Clearance 16.3 in 17.7 in (drawbar bracket) Min. Turn Radius without Brakes 2WD: 11.2 ft; 4WD: 11.8 ft 13.8 ft Height to Top of ROPS 97.2 in 99.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in Not Applicable Overall Length 2WD: 140.4 in; 4WD: 135.6 in 155.9 in ▶ WeightTractor Weight (Base) 2WD: 4,475 lb; 4WD: 4,608 lb 6,283 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 7.5-16 (2WD) or 9.5-24 (4WD) front, 16.9-30 rear Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural - Front 2WD: 7.5-16; 4WD: 9.5-24 12.4-24 R1 Agricultural - Rear 16.9-30 18.4-30 R3 Turf - Front 29x12.5-15 or 27x9.5-15 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) R3 Turf - Rear 18.4-26 or 21.5L-16.1 18.4-26 R3 or 19.5L-24 R3 R4 Industrial - Front 14-17.5L (4WD) 9.5L-15 F2 (rib front paired with the R4 rear) R4 Industrial - Rear 16.9-24 (4WD) 19.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System LA1153: two-lever quick coupler Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional Loader Model LA1153 LA1854 Loader Lift Height LA1153 height position: 132.7 in; LA1153 power position: 117.2 in 145.7 in (height position); 131.9 in (power position) Loader Lift Capacity (Full Height) Not Published 3,990 lb (height position); 4,144 lb (power position) Loader Breakout Force Not Published LA1854: 5,501 lbf (height position); 6,470 lbf (power position) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
