▶ EngineEngine Manufacturer Kubota Kubota Engine Model V3307-DI V3307-CR-TE4 Engine Type 4-cylinder inline, direct injected diesel Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 4 4 Displacement 203 in³ 203 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) Not Published 66.4 hp PTO Power 62 hp 56 hp Engine Emissions Constraints Tier 2 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner 8 in dry, dual element Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Direct injection Common Rail System (CRS) Alternator ROPS: 45 A, 12 V; Cab: 60 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 11.0 gpm 11.0 gpm Steering Flow 6.1 gpm 6.1 gpm Total Hydraulic Flow 17.1 gpm (11.0 + 6.1, computed) 17.1 gpm Overall Hydraulic Pump Flow 17.2 gpm 17.1 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 11.0 gpm 11.0 gpm No. of Standard Remote Valves 1 1 (SCD) No. of Optional Remote Valves 2nd and 3rd optional 2nd, 3rd (optional) ▶ Fluid CapacityFuel Tank Capacity ROPS: 18.5 gal; Cab: 29.1 gal 18.5 gal Coolant Capacity 8.5 qt 8.5 qt Crankcase Capacity 11.6 qt 12.7 qt Transmission / Hydraulic System Capacity 10.6 gal 14.8 gal Front Axle Fluid Capacity 8.5 qt 5.8 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Live independent PTO, hydraulically operated wet clutch with PTO brake Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 rpm 540 rpm (540/540E optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II I / II Hitch Lift Capacity 4189 lb 4189 lb Hitch Lift Capacity (at 24”) 3307 lb 3307 lb Lift Control Type Position, draft (top link sensing) and mix control Position, Draft (Top Link Sensing) & Mixed Control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models Hydraulic-shuttle transmission (fully synchronized) No. of Speeds 8F/8R (12F/12R with optional creep) F8/R8 Max Travel Speed (Forward) 18.7 mph 18.0 mph Max Travel Speed (Reverse) Not Published 17.7 mph Clutch Dry single plate (synchro shuttle) / multiple wet disks (hydraulic shuttle) Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock (bevel gears) Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS (canopy optional); Ultra Grand Cab optional Two-post foldable ROPS Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanically operated wet disc brakes Mechanical wet disc Seat Suspension & Adjustability Reclining, fully adjustable seat (height, weight, fore and aft, arm rests) with retractable seat belt; optional air ride seat suspension (cab) Fully adjustable suspension seat (travel, suspension tension, backrest tilt, arm rests); optional air ride seat on cab models Front Axle Type 4WD: Bevel gear type with Easy-To-Shift 4WD engagement while rolling Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5290 lb (6615 lb with loader) Drawbar Capacity 2200 lb 2200 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 140.4 in; 4WD: 135.6 in 138.0 in Overall Width 73.2 in 73.0 in Wheelbase 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in 83.1 in Ground Clearance 16.3 in 18.1 in Min. Turn Radius without Brakes 2WD: 11.2 ft; 4WD: 11.8 ft 11.8 ft Height to Top of ROPS 97.2 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.2 in 100.6 in ▶ WeightTractor Weight (Base) 2WD ROPS: 4675 lb; 4WD ROPS: 4805 lb 5005 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard: 7.5-16 (2WD) or 9.5-24 (4WD) front, 16.9-30 rear Standard: 9.5-24 front, 16.9-28 rear R1 Agricultural - Front 2WD: 7.5-16; 4WD: 9.5-24 9.5-24 R1 Agricultural - Rear 16.9-30 16.9-28/14.9-28 R3 Turf - Front 29x12.5-15 or 27x9.5-15 LSW305-521 R3 Turf - Rear 18.4-26 or 21.5L-16.1 LSW570-648 R4 Industrial - Front 14-17.5L (4WD) 12.5/80-18 R4 Industrial - Rear 16.9-24 (4WD) 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System LA1153: two-lever quick coupler LA1154A: 2-Lever Quick Coupler Loader Model LA1153 LA1154A Loader Lift Height LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Height position: 132.7 in; Power position: 117.2 in Loader Lift Capacity (Full Height) Not Published Height position: 2469 lb; Power position: 2928 lb Loader Breakout Force Not Published Height position: 4230 lbf; Power position: 5354 lbf ▶ WarrantyWarranty Length & Coverage Not Published 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
