▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403CR-T V2403-CR-TIE5 Engine Type Common rail direct injection, liquid-cooled, turbocharged 4-cylinder diesel Direct injection, water-cooled, 4-cycle diesel, common rail system, turbocharged and intercooled No. of Cylinders 4 4 Displacement 148.6 in³ 148.5 in³ Rated Engine Speed 2700 rpm 2300 rpm Engine Power (Gross) 54.7 hp 60 hp PTO Power F (2WD gear), DT (4WD gear): 45.7 hp; HST (4WD): 44.2 hp 53 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry, dual element Not Published Fuel System Common rail direct injection Common rail direct injection Alternator 45 A Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.5 gpm 9.83 gpm Steering Flow 4.9 gpm Not Published Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 (optional) Up to 3 (optional) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal Not Published Coolant Capacity 6.9 qt Not Published Crankcase Capacity 9.9 qt Not Published Transmission / Hydraulic System Capacity 11.6 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live independent hydraulic PTO with PTO brake, wet clutch Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity Not Published 3858 lb Hitch Lift Capacity (at 24”) 2310 lb 2976 lb Lift Control Type Position control standard, draft control optional Not Published ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): Gear-drive with synchronized shuttle, 8F/8R (4-speed main, partially synchronized 3rd and 4th, 2-range); HST (4WD): Hydrostatic transmission, 3-range Hydrostatic transmission, 3-range, with Hydro-Dual Speed (H-DS) No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 3-range Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 16.0 mph; HST (4WD): 16.1 mph 18.5 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 14.7 mph; HST (4WD): 14.5 mph Not Published Clutch F (2WD gear), DT (4WD gear): Dry single plate; HST (4WD): No clutch Not Published Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Two-post folding ROPS; cab optional Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet disc Wet disc type Seat Suspension & Adjustability High-back suspension seat Not Published Front Axle Type 4WD: Bevel gear type Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1650 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 127.8 in; DT (4WD gear), HST (4WD): 125.2 in (w/o 3P) (without 3-point hitch) 133.9 in (w/o 3P) (without 3-point hitch) Overall Width 69.7 in 67.3 in Wheelbase 74.6 in 81.3 in Ground Clearance F (2WD gear): 15.9 in; DT (4WD gear), HST (4WD): 15.2 in 15.4 in Min. Turn Radius without Brakes F (2WD gear): 8.5 ft; DT (4WD gear), HST (4WD): 8.9 ft (w/brake) (with brake applied) 9.5 ft (w/brake) (with brake applied) Height to Top of ROPS 95.7 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 93.3 in ▶ WeightTractor Weight (Base) F (2WD gear): 3474 lb; DT (4WD gear): 3716 lb; HST (4WD): 3734 lb 4387 lb (ROPS); 4762 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 7.5L-15 (2WD) or 9.5-16 (4WD) front, 14.9-26 rear Standard: 9.5-16 front, 14.9-26 rear R1 Agricultural - Front F (2WD gear): 7.5L-15; DT (4WD gear), HST (4WD): 9.5-16 9.5-16 R1 Agricultural - Rear 14.9-26 14.9-26 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA1065: 2-lever quick coupler standard LA1056, LM1056: toolless loader removal with integrated parking stands; optional third-function valve Loader Model LA1065 LA1056; LM1056 Loader Lift Height LA1065: 111.2 in LA1056: 117 in; LM1056: 117 in Loader Lift Capacity (Full Height) LA1065: 2275 lb LA1056: 2427 lb; LM1056: 2471 lb Loader Breakout Force Not Published LA1056: 4069 lbf; LM1056: 4061 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
