▶ EngineEngine Manufacturer Kubota LS Mtron Engine Model V2403CR-T L3CRV-T7 Engine Type Common rail direct injection, liquid-cooled, turbocharged 4-cylinder diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 4 3 Displacement 148.6 in³ 114.7 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 54.7 hp 55 hp PTO Power F (2WD gear), DT (4WD gear): 45.7 hp; HST (4WD): 44.2 hp Gear: 46.7 hp; HST: 44 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry, dual element Replaceable primary and inner elements Fuel System Common rail direct injection Electronically controlled common rail direct injection Alternator 45 A ROPS: 70 A, 12 V; Cab: 85 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 9.5 gpm 8.2 gpm Steering Flow 4.9 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow 14.4 gpm (9.5 + 4.9, computed) Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow Not Published Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Up to 3 (optional) Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal ROPS: 10.5 gal; Cab: 12.4 gal Coolant Capacity 6.9 qt 2.3 gal Crankcase Capacity 9.9 qt 5.8 qt Transmission / Hydraulic System Capacity 11.6 gal 11.4 gal Front Axle Fluid Capacity Not Published 2.2 gal ▶ PTO & HitchPTO Type Live independent hydraulic PTO with PTO brake, wet clutch Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard (2000 rpm) Category, 3-Point Hitch Category I and II Category I Hitch Lift Capacity Not Published 2,756 lb Hitch Lift Capacity (at 24”) 2310 lb 2,116 lb Lift Control Type Position control standard, draft control optional Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): Gear-drive with synchronized shuttle, 8F/8R (4-speed main, partially synchronized 3rd and 4th, 2-range); HST (4WD): Hydrostatic transmission, 3-range Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Gear: 16F/16R; HST: 3-range Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 16.0 mph; HST (4WD): 16.1 mph Gear: 17.0 mph; HST: 17.9 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 14.7 mph; HST (4WD): 14.5 mph Gear: 15.3 mph; HST: 11.37 mph Clutch F (2WD gear), DT (4WD gear): Dry single plate; HST (4WD): No clutch Gear: dry single disc (10.8 in); HST: n/a Differential Lock & Limited Slip Options Rear differential lock standard (mechanical) Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Not Published Steering Hydrostatic power steering Power steering Brakes Mechanical wet disc Wet multi-disc Seat Suspension & Adjustability High-back suspension seat ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests Front Axle Type 4WD: Bevel gear type Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity 1650 lb Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 127.8 in; DT (4WD gear), HST (4WD): 125.2 in (w/o 3P) (without 3-point hitch) 128.1 in Overall Width 69.7 in 69.1 in Wheelbase 74.6 in 73.2 in Ground Clearance F (2WD gear): 15.9 in; DT (4WD gear), HST (4WD): 15.2 in 15 in Min. Turn Radius without Brakes F (2WD gear): 8.5 ft; DT (4WD gear), HST (4WD): 8.9 ft (w/brake) (with brake applied) 111.8 in (right turn); 123.2 in (left turn) (with brake applied) Height to Top of ROPS 95.7 in 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94 in ▶ WeightTractor Weight (Base) F (2WD gear): 3474 lb; DT (4WD gear): 3716 lb; HST (4WD): 3734 lb ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard ag: 7.5L-15 (2WD) or 9.5-16 (4WD) front, 14.9-26 rear R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front F (2WD gear): 7.5L-15; DT (4WD gear), HST (4WD): 9.5-16 9.5-16 R1 Agricultural - Rear 14.9-26 13.6-24 R3 Turf - Front Not Published 28x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 12x16.5 R4 Industrial - Rear Not Published 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System LA1065: 2-lever quick coupler standard New Holland Quick Mount loader; optional skid steer quick attach plates Loader Model LA1065 260TLA Loader Lift Height LA1065: 111.2 in 260TLA: 109 in Loader Lift Capacity (Full Height) LA1065: 2275 lb 260TLA: 2,371 lb Loader Breakout Force Not Published 260TLA: 4,081 lb ▶ WarrantyWarranty Length & Coverage Not Published Boomer Guard6 limited warranty: 2 years/750 hours full coverage plus 4 more years of powertrain coverage (6 years/1,500 hours total)
