▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV80F Not Published Engine Type 3-cylinder, indirect injection (swirl chamber), water-cooled 3-cylinder, Tier 4 B/Final, indirect-injection, water-cooled No. of Cylinders 3 3 Displacement 77.3 in³ 77.3 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 24.7 hp 24.7 hp PTO Power 17.2 hp 17.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Dry Not Published Fuel System In-line injection pump Indirect injection Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Gear pump, transmission driven Not Published Implement Flow 4.6 gpm 4.6 gpm Steering Flow 2.1 gpm Not Published Total Hydraulic Flow 6.7 gpm Not Published Overall Hydraulic Pump Flow 6.7 gpm Not Published Hydraulic System Type Open center system, position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None None No. of Optional Remote Valves 1 set (2 quick couplers, optional) 1 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity 0.9 gal Not Published Crankcase Capacity 0.8 gal Not Published Transmission / Hydraulic System Capacity 3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe) Not Published Front Axle Fluid Capacity 0.5 gal Not Published ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Independent, electro-hydraulic engagement PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Standard (2,500 rpm) Standard, 2,500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 992 lb 992 lb Hitch Lift Capacity (at 24”) 728 lb 728 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic Drive 2-range hydrostatic (wet clutch) No. of Speeds 2 ranges Infinite, 2-range hydrostatic Max Travel Speed (Forward) 8.70 mph Not Published Max Travel Speed (Reverse) 5.22 mph Not Published Clutch N/A Wet clutch Differential Lock & Limited Slip Options Mechanical pedal type Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Not Published Seat Suspension & Adjustability Adjustable forward and backward via seat lever; reversible seat optional Not Published Front Axle Type Front wheel mechanical assist (4WD) Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal Not Published ▶ Dimensions & ManeuverabilityOverall Width 47 in Not Published Wheelbase 56 in 56 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 7.87 ft Not Published Height to Top of ROPS 87 in 87.4 in Height to Top of ROPS (folded) Not Published 62.4 in Height to Top of Cab Model Not Published Not Applicable Overall Length 97 in (bumper to link) 97 in ▶ WeightTractor Weight (Base) 1,444 lb 1,444 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf R3 turf or R4 industrial R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 18x8.50-10 18x8.5-10 R3 Turf - Rear 26x12.0-12 26x12-12 R4 Industrial - Front 18x8.50-10 18x8.5-10 R4 Industrial - Rear 26x12.0-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published L320S Loader Model LL1102; LL1700; LL1001 L320S Loader Lift Height LL1001: 72.6 in (at pivot pin) 72 in Loader Lift Capacity (Full Height) LL1001: 902 lb (at pivot pin, maximum height) 693 lb Loader Breakout Force LL1001: 1,836 lb (at pivot pin) 1,426 lb ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Not Published
