▶ EngineEngine Manufacturer Yanmar Mitsubishi Engine Model 3TNV80F-ZXKLST Not Published Engine Type 3-cylinder, indirect injection (swirl chamber) 3-cylinder, turbocharged & aftercooled, Tier 4 B/Final No. of Cylinders 3 3 Displacement 77.3 in³ 80.4 in³ Rated Engine Speed 2800 rpm 2500 rpm Engine Power (Gross) 24.7 hp 24.4 hp PTO Power 19.3 hp 17.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System In-line injection pump Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Engine driven Not Published Implement Flow 5.6 gpm 7.9 gpm Steering Flow 3.7 gpm Not Published Total Hydraulic Flow 9.3 gpm Not Published Overall Hydraulic Pump Flow 9.3 gpm Not Published Hydraulic System Type Open center system, position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 0 No. of Optional Remote Valves 1 pair (optional) 1 ▶ Fluid CapacityFuel Tank Capacity 6.79 gal 7.4 gal Coolant Capacity 0.9 gal Not Published Crankcase Capacity 0.8 gal Not Published Transmission / Hydraulic System Capacity 4.5 gal Not Published Front Axle Fluid Capacity 0.8 gal Not Published ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Independent PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Optional (2,500 rpm) Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,896 lb Not Published Hitch Lift Capacity (at 24”) 1,323 lb 1,433 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic Drive Hydrostatic (optional) No. of Speeds 3 ranges Infinite (hydrostatic) Max Travel Speed (Forward) 12.86 mph Not Published Max Travel Speed (Reverse) 8.45 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Not Published Seat Suspension & Adjustability Not Published Not Published Front Axle Type Four wheel drive (4WD) Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 48.7 in Not Published Wheelbase 63.4 in 65.9 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 8.2 ft (with brake) Not Published Height to Top of ROPS 86.4 in 88.2 in Height to Top of ROPS (folded) Not Published 68.2 in Height to Top of Cab Model Not Published Not Published Overall Length 111.9 in (frame to link) 117.2 in ▶ WeightTractor Weight (Base) 1,764 lb 2,469 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options IND (R4 Industrial), Versa Turf Not Published R1 Agricultural - Front 7-12 Not Published R1 Agricultural - Rear 11.2-16 Not Published R3 Turf - Front 22x8.50-12 Not Published R3 Turf - Rear 31x15.50-15 Not Published R4 Industrial - Front 23x8.50-12 Not Published R4 Industrial - Rear 12-16.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System LL2300: Bobcat type quick attach Not Published Loader Model LL2300; LL2001 L330 Loader Lift Height LL2300: 84.4 in; LL2001: 84.4 in 94.3 in Loader Lift Capacity (Full Height) LL2300: 1,067 lb; LL2001: 1,127 lb (at pivot pin) 1,214 lb Loader Breakout Force LL2300: 2,290 lb; LL2001: 1,744 lb (at pivot pin) 1,926 lb ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Basic 2 years; powertrain 4 additional years (6-year total)
