▶ EngineEngine Manufacturer LS TYM Engine Model L3C19-D2 A1700N4-BUTR_4 Engine Type 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI Vertical, 4-stroke, water-cooled diesel No. of Cylinders 3 3 Displacement 114.7 in³ 104.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power 29.7 hp 29.5 hp Engine Emissions Constraints Tier 4 EPA Final Tier4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Not Published Fuel System CRDI (Delphi common rail direct injection) Not Published Alternator 70 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Not Published Implement Flow 8.2 gpm 8.2 gpm Steering Flow 4.1 gpm 4.4 gpm Total Hydraulic Flow 12.3 gpm 12.6 gpm Overall Hydraulic Pump Flow 12.3 gpm 12.6 gpm Hydraulic System Type Open center system, position control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves 1 or 2 pairs (optional) Up to 2 ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 7.13 gal Coolant Capacity 1.9 gal 1.32 gal Crankcase Capacity 1.5 gal 1.14 gal Transmission / Hydraulic System Capacity 8.5 gal 9.77 gal Front Axle Fluid Capacity 1.7 gal 1.69 gal ▶ PTO & HitchPTO Type Independent (wet disc clutch) Independent PTO Rear Standard (540 rpm) 540 rpm Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 3,307 lb Hitch Lift Capacity (at 24”) 1,433 lb 2,425 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Synchro Shuttle Hydrostatic (HST), 3-range No. of Speeds F12 x R12 3 range (HST) Max Travel Speed (Forward) 14.33 mph 19.08 mph Max Travel Speed (Reverse) 13.63 mph 19.08 mph Clutch Dry single clutch None (HST) Differential Lock & Limited Slip Options Mechanical pedal type Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Front wheel mechanical assist (4WD) Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54 in 56.7 in Wheelbase 69 in 65.7 in Ground Clearance Not Published 13.1 in Min. Turn Radius without Brakes 10.79 ft (left); 11.02 ft (right) Not Published Height to Top of ROPS 88 in 96.85 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 121 in (frame to link) 134.88 in ▶ WeightTractor Weight (Base) 2,866 lb 3,164 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 ag 8.0-16 / 12.4-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20 R1 Agricultural - Front 7-14 8.0-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front 25x8.50-14 Not Published R3 Turf - Rear 41x14-20 Not Published R4 Industrial - Front 27x8.50-14 28x8.50-15 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published SSQA Loader Model LL3302 BBL400 Loader Lift Height 94 in 104 in Loader Lift Capacity (Full Height) LL3302: 2,153 lb (at pivot pin, full height) 2,200 lb (at pivot pin) Loader Breakout Force LL3302: 3,579 lb (at pivot pin) 3,660 lb ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
