▶ EngineEngine Manufacturer LS Mtron John Deere Engine Model L3C19-T CD3029DLV50 Engine Type 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI 3-cylinder, naturally aspirated, direct injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 114.7 in³ 179 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) 52 hp 53 hp PTO Power 41.6 hp 45 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry type with safety element Fuel System Common rail direct injection (CRDI) Direct injection, rotary injection pump, electric shutoff Alternator 70 A, 12 V 40 A ▶ HydraulicsPump Type Not Published Tandem gear pump Implement Flow 8.2 gpm 11.4 gpm Steering Flow 4.1 gpm 6.8 gpm Total Hydraulic Flow 12.3 gpm 18.2 gpm Overall Hydraulic Pump Flow 12.3 gpm 18.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.4 gpm No. of Standard Remote Valves 2 Pair (1 Detent, 1 STD) Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 18 gal (open station); 22 gal (cab) Coolant Capacity Not Published 10 qt Crankcase Capacity 6.2 qt 9 qt Transmission / Hydraulic System Capacity Not Published 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) Front Axle Fluid Capacity Not Published 5.3 qt (MFWD differential housing); 0.63 qt (each wheel hub) ▶ PTO & HitchPTO Type Independent Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch PTO Rear 540 rpm 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) Mid-PTO Availability Optional (2,000 rpm) Not Published Category, 3-Point Hitch Category II Category I and II Hitch Lift Capacity 2,755 lb Not Published Hitch Lift Capacity (at 24”) 2,469 lb 3,374 lb Lift Control Type Position & Draft Position and depth control, top link draft sensing ▶ Transmission & DrivetrainTransmission Type Synchro shuttle CollarShift standard; SyncShuttle optional; PowrReverser optional No. of Speeds F16 x R16 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) Not Published 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) Max Travel Speed (Reverse) Not Published 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) Clutch Not Published Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Differential Lock & Limited Slip Options Mechanical differential lock (pedal type) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS; cab optional; two-wheel drive or MFWD Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet, Multi-disc Wet disk, self-equalizing, self-adjusting Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front-wheel drive (4WD) Two-wheel drive or mechanical front wheel drive (MFWD) Front Axle Rating Not Published 2,720 to 4,700 lb (2WD, by front tire, no loader); 2,760 to 4,620 lb (MFWD, by front tire, without loader) Drawbar Capacity Not Published 1,675 lb (maximum permissible static vertical load, drawbar fully extended) ▶ Dimensions & ManeuverabilityOverall Width 62.5 in 94.6 in (maximum) Wheelbase 73.2 in 80.7 in Ground Clearance Not Published 19 in (2WD front axle); 17 in (MFWD front axle); 14.3 in (drawbar) Min. Turn Radius without Brakes Not Published 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) Height to Top of ROPS H: 95 in 88.7 in (extended) Height to Top of ROPS (folded) Not Published 76.7 in Height to Top of Cab Model Not Applicable 97 in Overall Length 133 in (frame to link) 122.6 in (2WD); 125.9 in (MFWD) (less drawbar and front weights) (without 3-point hitch) ▶ WeightTractor Weight (Base) 3,869 lb 4,370 lb (2WD); 4,730 lb (MFWD); add 1,000 lb with cab Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Published ▶ Tire OptionsTire Size & Options Agricultural, Turf, Industrial Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 18.4-16.1 R1 Agricultural - Front 9.5-16 8.3-24 (MFWD) R1 Agricultural - Rear 13.6-24 13.6-28 R3 Turf - Front 28x8.5-15 Not Published R3 Turf - Rear 41x14-20 Not Published R4 Industrial - Front 12-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System LL4106, LL4001: 2-lever skid-steer coupler, fits universal skid-steer attachments Not Published Loader Model LL4106; LL4001 521; 541; 541 self-leveling; 542; 542 self-leveling Loader Lift Height LL4106: 94.4 in; LL4001: 104.3 in 521: 122 in; 541: 126 in; 541 self-leveling: 130 in Loader Lift Capacity (Full Height) LL4106: 2,680 lb (at pivot pin); LL4001: 2,998 lb (at pivot pin) 521: 2,500 lb; 541: 2,500 lb; 541 self-leveling: 2,800 lb (full at pin) Loader Breakout Force LL4106: 4,063 lb (at pivot pin); LL4001: 4,295 lb (at pivot pin) 521: 3,485 lbf; 541: 3,484 lbf; 541 self-leveling: 4,125 lbf (at pin) ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain warranty Not Published
