▶ EngineEngine Manufacturer LS Mtron John Deere Engine Model L4C25-T PowerTech PWL 4045 Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI Diesel, turbocharged, aftercooled No. of Cylinders 4 4 Displacement 152.9 in³ 276 in³ Rated Engine Speed 2500 rpm 2400 rpm Engine Power (Gross) 73 hp 100 hp PTO Power 62 hp 85 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Dry type with safety element Fuel System Not Published High Pressure Common Rail Alternator 70 A, 12 V OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Gear type, engine drive Tandem gear pump (implement + steering) Implement Flow 13.2 gpm 15.9 gpm Steering Flow 6.6 gpm 6.6 gpm Total Hydraulic Flow 19.8 gpm 22.5 gpm Overall Hydraulic Pump Flow 19.8 gpm 22.5 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 Pairs (Front), 3 Pairs (Rear) 2 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 26.4 gal OOS: 25 gal; Cab: 30 gal Coolant Capacity 2.6 gal Cab: 3 gal; OOS: 2.5 gal Crankcase Capacity 2.1 gal 3.2 gal (with filter) Transmission / Hydraulic System Capacity 14.5 gal 11.5 gal Front Axle Fluid Capacity 1.5 gal MFWD differential housing: 1.3 gal; MFWD wheel hub (each): 0.74 qt ▶ PTO & HitchPTO Type Independent Independent, electrohydraulic engagement PTO Rear 540 / 750 / 1,000 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 6,614 lb Not Published Hitch Lift Capacity (at 24”) 4,718 lb 4,630 lb Lift Control Type Position & Draft Top link draft sensing; mechanical hitch controls ▶ Transmission & DrivetrainTransmission Type MT573C: Synchro Shuttle; MT573CPS: Power Shuttle PowrReverser No. of Speeds F20 x R20 12F/12R (standard); 24F/12R (optional) Max Travel Speed (Forward) 19.4 mph 12F/12R: 21.7 mph; 24F/12R: 24.9 mph (electronically limited) Max Travel Speed (Reverse) Not Published Not Published Clutch MT573C: Dry single clutch; MT573CPS: Wet clutch disks Wet traction clutch Differential Lock & Limited Slip Options Electro-hydraulic differential lock (EHD) Pedal-operated differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Not Published Hydraulic wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Air suspension seat (10° swivel) Not Published Front Axle Type Not Published Mechanical front wheel drive (MFWD) Front Axle Rating Not Published 6,615 lb Drawbar Capacity Not Published Standard: 2,755 lb; 2,425 lb (350 and 15.7 in extended). Heavy-Duty: 3,195 lb; 2,645 lb (350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width 77.5 in Not Published Wheelbase 84.6 in 92.5 in Ground Clearance Not Published ROPS: 17 in; Cab: 15.2 in Min. Turn Radius without Brakes 13.0 ft Not Published Height to Top of ROPS Not Published 100.8 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model 104.4 in 101.2 in Overall Length 150 in (frame to link) 159.13 in ▶ WeightTractor Weight (Base) MT573C: 6,620 lb; MT573CPS: 6,669 lb OOS: 7,275 lb (shipping weight); Cab: 8,150 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader MT573C: 7,852 lb (6,620 + 1,232, computed); MT573CPS: 7,901 lb (6,669 + 1,232, computed) Not Published ▶ Tire OptionsTire Size & Options Ag 11.2-24 / 16.9-30; R14 W320/85R24 122D / W460/85R30 145D Not Published R1 Agricultural - Front 11.2-24 12.4-24 R1 Agricultural - Rear 16.9-30 18.4-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System LL6100: Bobcat-type quick attachment (ISO 24410), latch handle with latch pin 520M; 540M Loader Model LL6100 520M and 540M (previously H240 and H260) Loader Lift Height LL6100: 126.5 in 520M MSL: 132.0 in Loader Lift Capacity (Full Height) LL6100: 3,626 lb (at pivot pin) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force LL6100: 6,644 lb (at pivot pin) 520M MSL: 4,793 lb (measured at pivot) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 6 years or 1,500 hours Not Published
