▶ EngineEngine Manufacturer LS Mtron FPT (Fiat Power Train) Engine Model L4C25-T F34 Engine Type In-line vertical, water cooled 4-cycle diesel, CRDI 4-cylinder, CRDI, water-cooled No. of Cylinders 4 4 Displacement 152.9 in³ 206.7 in³ Rated Engine Speed 2500 rpm 2200 rpm Engine Power (Gross) 73 hp 73.7 hp PTO Power 62 hp 65.6 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Dry Not Published Fuel System Not Published Not Published Alternator 70 A, 12 V Not Published ▶ HydraulicsPump Type Gear type, engine drive Gear pump type, engine drive Implement Flow 13.2 gpm 15.7 gpm Steering Flow 6.6 gpm 6.5 gpm Total Hydraulic Flow 19.8 gpm 22.2 gpm Overall Hydraulic Pump Flow 19.8 gpm 22.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 Pairs (Front), 3 Pairs (Rear) 3 Pairs (Front), 2 Pairs (Rear) No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 26.4 gal 30.4 gal Coolant Capacity 2.6 gal Not Published Crankcase Capacity 2.1 gal Not Published Transmission / Hydraulic System Capacity 14.5 gal 14.5 gal Front Axle Fluid Capacity 1.5 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 / 750 / 1,000 540 / 750 / 1,000 Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 6,614 lb 7,275 lb Hitch Lift Capacity (at 24”) 4,718 lb 5,181 lb Lift Control Type Position & Draft Position & Draft ▶ Transmission & DrivetrainTransmission Type MT573C: Synchro Shuttle; MT573CPS: Power Shuttle Power Shuttle No. of Speeds F20 x R20 24 X 24 Max Travel Speed (Forward) 19.4 mph 20.8 mph Max Travel Speed (Reverse) Not Published Not Published Clutch MT573C: Dry single clutch; MT573CPS: Wet clutch disks Wet disks Differential Lock & Limited Slip Options Electro-hydraulic differential lock (EHD) Electro-Hydraulic Differential lock (EHD) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Not Published Wet, Multi-disc Seat Suspension & Adjustability Air suspension seat (10° swivel) Air suspension seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 77.5 in 78.7 in Wheelbase 84.6 in 90 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 13.0 ft Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 104.4 in 105 in Overall Length 150 in (frame to link) 152.2 in (frame to link) ▶ WeightTractor Weight (Base) MT573C: 6,620 lb; MT573CPS: 6,669 lb 7,827 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader MT573C: 7,852 lb (6,620 + 1,232, computed); MT573CPS: 7,901 lb (6,669 + 1,232, computed) 9,487 lb (7,827 + 1,660, computed; LL8100 loader without bucket) ▶ Tire OptionsTire Size & Options Ag 11.2-24 / 16.9-30; R14 W320/85R24 122D / W460/85R30 145D Ag 11.2-24 / 16.9-30; R14 320/85R24 / 460/85R30 R1 Agricultural - Front 11.2-24 11.2-24 R1 Agricultural - Rear 16.9-30 16.9-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System LL6100: Bobcat-type quick attachment (ISO 24410), latch handle with latch pin Not Published Loader Model LL6100 LL8100 Loader Lift Height LL6100: 126.5 in LL8100: 139.9 in Loader Lift Capacity (Full Height) LL6100: 3,626 lb (at pivot pin) LL8100: 5,139 lb (at pivot pin) Loader Breakout Force LL6100: 6,644 lb (at pivot pin) LL8100: 5,313 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 6 years or 1,500 hours Basic 2 years or 750 hours; powertrain 5 years or 1,500 hours
