▶ EngineEngine Manufacturer Mitsubishi (MHI) Yanmar Engine Model S3L2 3TNV88F-EPJT2 Engine Type Indirect injection, swirl chamber diesel Diesel, naturally aspirated, direct injection No. of Cylinders 3 3 Displacement 80.4 in³ 100.2 in³ Rated Engine Speed 2500 rpm 2400 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power XG3025 (gear): 19.2 hp; XG3025H (HST): 17.1 hp 19.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water pump Air Cleaner Dry Dry type with safety element Fuel System Indirect injection Direct injection Alternator 50 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Gear pump, engine driven Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump Implement Flow 7.9 gpm 5.3 gpm Steering Flow 4.6 gpm 4.0 gpm Total Hydraulic Flow 12.5 gpm 9.3 gpm Overall Hydraulic Pump Flow 12.5 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves Optional (double acting, 2 or 4 quick couplers) Up to 2 (optional) ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 7.5 gal Coolant Capacity 1.3 gal 5.2 qt Crankcase Capacity 1.1 gal 4.5 qt Transmission / Hydraulic System Capacity 8.5 gal 5.5 gal Front Axle Fluid Capacity 1.7 gal 4 qt ▶ PTO & HitchPTO Type Independent Not Published PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb Not Published Hitch Lift Capacity (at 24”) 1,433 lb 1,356 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type XG3025 (gear): Synchro shuttle; XG3025H (HST): HST Hydrostatic transmission (HST) No. of Speeds XG3025 (gear): F12 x R12; XG3025H (HST): 3 ranges (HST) Not Published Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch XG3025 (gear): dry single clutch; XG3025H (HST): n/a Not Published Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Open operator station (OOS) Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD (MFWD) Front Axle Rating Not Published 1,760 lb Drawbar Capacity Not Published 880 lb (maximum vertical load) ▶ Dimensions & ManeuverabilityOverall Width 54 in 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 66 in 62.8 in Ground Clearance Not Published 12.7 in (R4 tires) Min. Turn Radius without Brakes 10.5 ft Not Published Height to Top of ROPS 88 in 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 118 in (frame to link) 115.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) XG3025 (gear): 2,434 lb; XG3025H (HST): 2,469 lb 2,222 lb Weight with ROPS and Loader Not Published 2,972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.5-14 27X8.50-15 R3 Turf - Rear 41x14-20 41X14-20 R4 Industrial - Front 25x8.5-14 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear 43x16-20 15-19.5 or 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-change attachment carrier Loader Model LL3110 300E Loader Lift Height LL3110: 94.3 in 84 in (at pivot pin) Loader Lift Capacity (Full Height) LL3110: 1,600 lb (at pivot pin) 1,186 lb (at pivot pin) Loader Breakout Force LL3110: 2,637 lb (at pivot pin) 1,704 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours
