▶ EngineEngine Manufacturer LS LS Mtron Engine Model L3C19-T5 L3C19-T5 Engine Type Vertical, water-cooled, 4-cycle diesel Diesel, 3-cylinder, turbocharged No. of Cylinders 3 3 Displacement 114.7 in³ 115.9 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power XR3135, XR3135C (gear): 29.7 hp; XR3135H, XR3135HC (HST): 28 hp 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Not Published Air Cleaner Dry Replaceable dry element Fuel System CRDI (common rail direct injection) Common rail direct injection Alternator 70 A, 12 V 70 A ▶ HydraulicsPump Type Gear pump, engine driven Not Published Implement Flow 8.2 gpm 8.2 gpm Steering Flow XR3135, XR3135C (gear): 4.1 gpm; XR3135H, XR3135HC (HST): 5.5 gpm 5.3 gpm Total Hydraulic Flow XR3135, XR3135C (gear): 12.3 gpm; XR3135H, XR3135HC (HST): 13.7 gpm 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow XR3135, XR3135C (gear): 12.3 gpm; XR3135H, XR3135HC (HST): 13.7 gpm Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 pairs 1 No. of Optional Remote Valves Optional (2 or 6 quick couplers) 2 ▶ Fluid CapacityFuel Tank Capacity XR3135, XR3135H (ROPS): 10.6 gal; XR3135C, XR3135HC (cab): 12.4 gal 10.5 gal Coolant Capacity 1.9 gal Not Published Crankcase Capacity 1.5 gal Not Published Transmission / Hydraulic System Capacity 7.9 gal Not Published Front Axle Fluid Capacity 1.7 gal Not Published ▶ PTO & HitchPTO Type Independent Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm (3-speed 540/750/1000 optional) 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb Not Published Hitch Lift Capacity (at 24”) 1,433 lb 1,808 lb Lift Control Type Position and draft control Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type XR3135, XR3135C (gear): Synchro shuttle; XR3135H, XR3135HC (HST): HST 3-range hydrostatic (HST) No. of Speeds XR3135, XR3135C (gear): F12 x R12; XR3135H, XR3135HC (HST): 3 ranges (HST) Infinitely variable, 3 ranges Max Travel Speed (Forward) Not Published 14.8 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Mechanical: dry single clutch; HST: not applicable Not Applicable Differential Lock & Limited Slip Options Mechanical differential lock (pedal) Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Wet multi-disc Seat Suspension & Adjustability Not Published Adjustable suspension seat Front Axle Type Not Published Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 62 in 66.4 in Wheelbase 69 in 66 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.2 ft (with brake applied) Not Published Height to Top of ROPS 94 in 93.5 in Height to Top of ROPS (folded) Not Published 74.1 in Height to Top of Cab Model 86.6 in Not Applicable Overall Length 128.3 in (bumper to link) 122.5 in ▶ WeightTractor Weight (Base) XR3135 (gear, ROPS): 3,175 lb; XR3135H (HST, ROPS): 3,285 lb; XR3135C (gear, cab): 3,589 lb; XR3135HC (HST, cab): 3,655 lb 3,175 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.5-14 25x8.50-14 R3 Turf - Rear 41x14-20 41x14.00-20 R4 Industrial - Front 25x8.5-14 25x8.50-14 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System LL3106, LL3116: quick attach, skid steer compatible Quick-Attach faceplate; mid-mount frame with fast loader connect and disconnect (L350A) Loader Model LL3106; LL3116 L350A Loader Lift Height LL3106: 92.7 in; LL3116: 94.4 in 105 in Loader Lift Capacity (Full Height) LL3106: 2,178 lb; LL3116: 2,185 lb (at pivot pin) 1,540 lb at 31.5 in forward of pivot pin Loader Breakout Force LL3106: 3,450 lb; LL3116: 3,612 lb (at pivot pin) 2,640 lb ▶ WarrantyWarranty Length & Coverage 6-year limited warranty Basic 2 years; powertrain 4 additional years (6-year, 72-month total)
