▶ EngineEngine Manufacturer Shibaura (ISM) LS Mtron Engine Model N844L-F L3C19-T4 Engine Type 4-cylinder, indirect-injection, water-cooled Diesel, 3-cylinder, turbocharged No. of Cylinders 4 3 Displacement 135.2 in³ 115.9 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power XR4040, XR4040C (gear): 32.4 hp; XR4040H, XR4040HC (HST): 30.8 hp 32 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Not Published Air Cleaner Dry Replaceable dry element Fuel System Indirect injection Common rail direct injection Alternator 85 A, 12 V 70 A ▶ HydraulicsPump Type Gear pump type, engine drive Not Published Implement Flow 8.2 gpm 8.2 gpm Steering Flow XR4040, XR4040C (gear): 4.2 gpm; XR4040H, XR4040HC (HST): 5.5 gpm 5.3 gpm Total Hydraulic Flow XR4040, XR4040C (gear): 12.4 gpm; XR4040H, XR4040HC (HST): 13.7 gpm 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow XR4040, XR4040C (gear): 12.4 gpm; XR4040H, XR4040HC (HST): 13.7 gpm Not Published Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 pairs (4 front, 4 rear) 2 No. of Optional Remote Valves Optional (2 or 6 quick couplers) Not Published ▶ Fluid CapacityFuel Tank Capacity XR4040, XR4040H (ROPS): 10.5 gal; XR4040C, XR4040HC (cab): 12.4 gal 12.4 gal Coolant Capacity 2.0 gal Not Published Crankcase Capacity 1.5 gal Not Published Transmission / Hydraulic System Capacity 11.4 gal Not Published Front Axle Fluid Capacity 2.1 gal Not Published ▶ PTO & HitchPTO Type Independent Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,756 lb Not Published Hitch Lift Capacity (at 24”) 2,469 lb 1,808 lb Lift Control Type Position and draft control Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type XR4040, XR4040C (gear): Synchro shuttle; XR4040H, XR4040HC (HST): HST 3-range hydrostatic (optional) No. of Speeds XR4040, XR4040C (gear): F16 x R16; XR4040H, XR4040HC (HST): 3 ranges (HST) 3 ranges Max Travel Speed (Forward) Not Published 14.8 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single clutch (mechanical only) n/a (no clutch on hydrostatic) Differential Lock & Limited Slip Options Mechanical pedal type differential lock Mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Wet multi-disc Seat Suspension & Adjustability Not Published Deluxe seat with armrests and an adjustable backrest Front Axle Type Not Published Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 62.4 in 66.4 in Wheelbase 69.4 in 66 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.5 ft (with brake applied) Not Published Height to Top of ROPS 96.3 in Not Applicable Height to Top of ROPS (folded) Not Published Not Applicable Height to Top of Cab Model 91.1 in 93.3 in Overall Length 129.4 in (bumper to link) 128.1 in ▶ WeightTractor Weight (Base) XR4040, XR4040H (ROPS): 3,870 lb; XR4040C, XR4040HC (cab): 4,330 lb 3,803 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag, industrial or turf tires at no additional cost R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 9.5-16 Not Published R1 Agricultural - Rear 13.6-24 Not Published R3 Turf - Front 28x8.5-15 Not Published R3 Turf - Rear 41x14-20 Not Published R4 Industrial - Front 12-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System LL4102: quick attach, skid steer compatible Quick-Attach faceplate; mid-mount frame for fast loader connect and disconnect (L350A) Loader Model LL4102 L350A Loader Lift Height LL4102: 96.1 in 105 in Loader Lift Capacity (Full Height) LL4102: 2,500 lb (at pivot pin) 1,540 lb at 31.5 in. forward of pivot pin Loader Breakout Force LL4102: 4,354 lb (at pivot pin) 2,640 lbf ▶ WarrantyWarranty Length & Coverage 5-year limited warranty Basic 2 years; powertrain 4 additional years (6-year, 72-month total)
