▶ EngineEngine Manufacturer LS Mtron John Deere Engine Model L4C25-T2 PowerTech 3029 (2.9L) EWR Engine Type In-line vertical, Water cooled 4-cycle diesel, CRDI Diesel, turbocharged No. of Cylinders 4 3 Displacement 152.86 in³ 179 in³ Rated Engine Speed 2500 rpm 2100 rpm Engine Power (Gross) 68 hp 67.6 hp PTO Power 60 hp PR/TSS OOS: 55.3 hp; PR/TSS Cab: 53.3 hp; eHydro: 44.5 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid cooled Air Cleaner Dry Dry type with safety element Fuel System CRDI Electronically controlled, high-pressure common rail Alternator 70 A, 12 V 110 A ▶ HydraulicsPump Type Gear type, engine drive PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps Implement Flow 9.9 gpm 11.4 gpm Steering Flow 4.6 gpm 6.8 gpm Total Hydraulic Flow 14.5 gpm (9.9 + 4.6, computed) PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Overall Hydraulic Pump Flow Not Published PR/TSS: 18.2 gpm; eHydro: 29.6 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 21.1 gal OOS: 19 gal; Cab: 21 gal Coolant Capacity 2.4 gal Not Published Crankcase Capacity 1.8 gal 9.0 qt (with filter) Transmission / Hydraulic System Capacity 12.4 gal Not Published Front Axle Fluid Capacity 2.6 gal DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 (standard); 540 / 750 / 1,000 (optional 3-speed) 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II, convertible to I Hitch Lift Capacity 4,079 lb 3,968 lb Hitch Lift Capacity (at 24”) 3,483 lb 3,192 lb Lift Control Type Position and draft control Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type Synchro-shuttle (standard); Power shuttle (optional) SyncShuttle (standard); PowrReverser or eHydro (optional) No. of Speeds F16 x R16 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Max Travel Speed (Forward) 17.99 mph 15.5 mph (SyncShuttle) Max Travel Speed (Reverse) 14.81 mph Not Published Clutch Dry single clutch (mechanical); wet clutch disks (power shuttle) SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic Differential Lock & Limited Slip Options Mechanical pedal type differential lock Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet, multi-disc Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Adjustable drawbar with interchangeable hitch balls ▶ Dimensions & ManeuverabilityOverall Width 70 in Not Published Wheelbase 80.3 in 80.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.8 ft (with brake applied) 11.5 ft (2WD); 15.3 ft (MFWD) Height to Top of ROPS 103 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100.6 in Not Published Overall Length 138.6 in (bumper to link) 144.5 in ▶ WeightTractor Weight (Base) Roll-bar: 4,674 lb; Cabin: 5,121 lb (without ballast) 5,555 to 6,812 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag 9.5-20 / 16.9-24; Industrial 10.5/80-18 / 19.5L-24; Turf 36x13.5-15 / 16.9-24 Not Published R1 Agricultural - Front 9.5-20 MFWD: 11.2-24; 12.4-24 R1 Agricultural - Rear 16.9-24 16.9-28 R3 Turf - Front 36x13.5-15 Not Published R3 Turf - Rear 16.9-24 Not Published R4 Industrial - Front 10.5/80-18 Not Published R4 Industrial - Rear 19.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader Loader Model LL5106 500E, 500M or 520M Loader Lift Height LL5106: 116.3 in 500M: 124 in Loader Lift Capacity (Full Height) LL5106: 2,981 lb (at pivot pin) 500M: 3,225 lb (at pivot, full height) Loader Breakout Force LL5106: 4,767 lb (at pivot pin) 500M: 4,354 lb (at pivot) ▶ WarrantyWarranty Length & Coverage General: 2 years or 750 hours (whichever occurs first). Extended powertrain: 6 years or 1,500 hours (whichever occurs first), for tractors retailed after January 1, 2017 Not Published
