▶ EnginePTO Power 16.8 hp 28.7 (21.4) HP (kW) Alternator 55 A, 12 V — Air Cleaner Not Published LX2620: 4.5 inch paper filter (with dual filter); LX3520/LX4020: 6 inch paper filter (with dual element) Engine Type Four Stroke, Naturally Aspired, Indirect Injection, Water-Cooled Diesel Engine Indirect injection, vertical, water-cooled, 4-cycle diesel and Direct injection, vertical, water-cooled, 4-cycle diesel with turbocharger Fuel System Indirect Injection Common Rail (CRS) diesel Displacement 67.2 in³ 77 in³ No. of Cylinders 3 4 Rated Engine Speed 3000 rpm 2500 rpm Cooling System Type Water-Cooled Pressurized radiator with radial air flow fan Engine Manufacturer Mitsubishi Kubota Engine Power (Gross) 22.9 hp 23.3 hp Engine Emissions Constraints No DPF — ▶ WeightWeight with ROPS and Loader Not Applicable — Weight with Cab and Loader 2368 lb — Tractor Weight (Base) — LX2620: 1,775 lbs; LX3520DTN: 2,154 lbs; LX3520: 2,191 lbs; LX4020: 2,624 lbs ▶ WarrantyWarranty Length & Coverage 7-Year Limited Powertrain Warranty Full warranty: 2 years / 2,000 hours | Powertrain warranty: 6 years / 2,000 hours ▶ HydraulicsPump Type Not Published Dual pump Steering Flow 3.8 gpm — Implement Flow 7.6 gpm — Total Hydraulic Flow 11.4 gpm 9.1 (34.5) gpm (l/min.) Hydraulic System Type Open Center, full-live hydraulic with position control Open center Rear Remote Hydraulic Flow Not Published — Overall Hydraulic Pump Flow 11.4 gpm 9.1 (34.5) gpm (l/min.) No. of Optional Remote Valves Single or dual — No. of Standard Remote Valves Not Published — System Operating Pressure — Open center system ▶ PTO & HitchPTO Rear 540 rpm @ 2837 rpm 540 rpm PTO Type Independent Wet Clutch Independent Lift Control Type Position Control Position control valve Hitch Lift Capacity Not Published 2348 (1065) lbs. (kg) Mid-PTO Availability Optional; 2500 rpm @ 2837 rpm 2460 RPM Category, 3-Point Hitch CAT I with check chains Category I Hitch Lift Capacity (at 24”) 771 lb LX2620: 1,819 lbs; LX3520/LX4020: 1,962 lbs ▶ Tire OptionsR3 Turf - Rear 26X12-12 16.6-16 R3 Turf - Front 18X8.5-10 24x8.5-14 Tire Size & Options R3 Turf, R4 Industrial Front R1: 7-12; R4: 23×8.50-12; R4 large: 25×8.50-14; R14: 23×8.50-12; R14 large: 25×8.50-14; TURF: 24×8.50-14; Rear R1: 12.4-16; R4: 14-17.5; R14: 14-17.5; TURF: 13.6-16; R4 large: 15-19.5; R14 large: 15-19.5 R4 Industrial - Rear 26X12-12 14-17.5 or 15-19.5 R4 Industrial - Front 18X8.5-10 23x8.5-12 or 25x8.5-14 R1 Agricultural - Rear Not Published 320/85D16 R1 Agricultural - Front Not Published 180/85D12 ▶ Fluid CapacityCoolant Capacity Not Published LX2620: 4.5 qts (4.3 ℓ); LX3520/LX4020: 5.7 qts (5.4 ℓ) Crankcase Capacity Not Published LX2620: 4.2 qts (4.0 ℓ); LX3520/LX4020: 5.0 qts (4.7 ℓ) Fuel Tank Capacity 6.6 gal LX2620: 7.1 gal (27 ℓ); LX3520/LX4020: 8.5 gal (32 ℓ) Front Axle Fluid Capacity Not Published — Transmission / Hydraulic System Capacity Not Published 5.5 (21.0) gal (ℓ) ▶ Loader & AttachmentsLoader Lift Height 68 in 87.6 (2226) in. (mm) Loader Breakout Force 1433 lb — Quick Attach Loader System L11: Skid-steer couplers (skid-steer style quick attach) for superfast hookups. 2-Lever Quick Coupler (Standard); Swift-Tach (Optional) Loader Lift Capacity (Full Height) 794 lb 1100 (499) lbs. (kg) ▶ Transmission & DrivetrainClutch Not Applicable N/A No. of Speeds Infinite / 2 ranges HST (3 range) Transmission Type HST HST (3 ranges) Max Travel Speed (Forward) 7.3 mph 17.0 (0-27.4) mph (km/h) Max Travel Speed (Reverse) Not Published 13.0 (0-20.8) mph (km/h) Differential Lock & Limited Slip Options Not Published Standard ▶ Chassis, Steering & ControlsBrakes Single Pedal Multi-plate wet disk Steering Hydrostatic Power Steering Hydrostatic power steering Frame Type Not Published — Front Axle Type Not Published — Drawbar Capacity Not Published — Front Axle Rating Not Published — Seat Suspension & Adjustability Not Published Deluxe suspension seat (high back, designed to absorb shock) ▶ Dimensions & ManeuverabilityWheelbase 55.1 in 66.7 (1695) in. (mm) Overall Width 46.3 in 53.7 (1365) in. (mm) Ground Clearance 6.7 in 12.8 (325) in. (mm) Height to Top of ROPS Not Applicable LX3520 Narrow: 56.7 in. (folded) Height to Top of Cab Model 80.5 in — Height to Top of ROPS (folded) Not Published 56.7 (1440) in. (mm) Min. Turn Radius without Brakes Not Published 7.5 (2.3) feet (m) Front drive disengaged Overall Length with 3-Point Hitch 100.4 in 101.8 (2586) in. (mm) Overall Length — LX2620: 101.8 in.; LX3520DTN: 98.2 in.; LX3520/LX4020: 101.6-103.9 in. (2580-103.9 in)
