▶ EngineEngine Manufacturer Mitsubishi Shibaura Engine Model Not Published S773L Engine Type Three cylinder, four cycle, valve in cylinder head, cross flow porting diesel 3-cylinder diesel with pressurized radiator No. of Cylinders 3 3 Displacement 80.43 in³ 69.0 in³ Rated Engine Speed 2600 rpm 3000 rpm Engine Power (Gross) 26 hp 26 hp PTO Power 23 hp Not Published Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled, pressurized, thermostat controlled bypass, impeller pump Liquid-cooled Air Cleaner Dry type with double filter Not Published Fuel System Indirect injection; Bosch M type ND-PFR (Denso) injection pump, throttle type injectors Not Published Alternator 50 A Not Published ▶ HydraulicsPump Type Gear type, front mounted, engine driven Gear Implement Flow 7.8 gpm Not Published Steering Flow 3.4 gpm Not Published Total Hydraulic Flow 11.2 gpm (7.8 + 3.4, computed) 6.5 gpm Overall Hydraulic Pump Flow Not Published 6.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity Not Published 6.7 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent (3016 Gear Drive); Live (3016 Hydrostatic Drive) Independent PTO Rear 540 rpm @ 2376 rpm 540 rpm Mid-PTO Availability Optional; 2000 rpm @ 2525 rpm Standard (2,200 rpm) Category, 3-Point Hitch CAT I Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1720 lb Not Published Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, constant mesh main with 2 ranges (3016 Gear Drive); Hydrostatic, 3 ranges (3016 Hydrostatic Drive) Hydrostatic (HST) No. of Speeds 8F/8R (3016 Gear Drive); Infinite, 3 ranges (3016 Hydrostatic Drive) Infinite, 2 range Max Travel Speed (Forward) 11.9 mph (3016 Gear Drive); 13.8 mph (3016 Hydrostatic Drive) 10.3 mph Max Travel Speed (Reverse) 9.9 mph (3016 Gear Drive); 6.9 mph (3016 Hydrostatic Drive) 7.0 mph Clutch Dry single disc, diaphragm type, 8.46 in Not Published Differential Lock & Limited Slip Options Mechanical differential lock, pedal actuated Rear differential lock (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet disc, mechanical Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front drive (MFD), spiral bevel gear differential with bevel gear reductions 4WD Front Axle Rating Not Published Not Published Drawbar Capacity 969 lbf Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121.3 in 98.1 in Overall Width 63 in Not Published Wheelbase 67.3 in 55.1 in Ground Clearance 11.4 in 6.4 in Min. Turn Radius without Brakes 7.9 ft (with brake applied) Not Published Height to Top of ROPS 81.5 in 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2437 lb (3016 Gear Drive); 2459 lb (3016 Hydrostatic Drive) Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R3 Turf and R4 Industrial: 18x8.5-10 front, 26x12.00-12 rear R1 Agricultural - Front 7x16 Not Published R1 Agricultural - Rear 11.2x24 Not Published R3 Turf - Front 25x8.5-14 18x8.5-10 R3 Turf - Rear 13.6x16 26x12.00-12 R4 Industrial - Front 27x8.50-15 18x8.5-10 R4 Industrial - Rear 15x19.5 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach (QA) bucket, 48 in Loader Model ML115 SL2410 Loader Lift Height ML115: 99 in SL2410: 71.3 in Loader Lift Capacity (Full Height) ML115: 1,650 lb SL2410: 675.3 lb Loader Breakout Force ML115: 2,650 lb SL2410: 1,332 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
