▶ EngineEngine Manufacturer Mitsubishi Mitsubishi Engine Model Not Published MVL3E3 Engine Type Three cylinder, four cycle, valve in cylinder head, cross flow porting diesel Four Stroke, Naturally Aspired, Indirect Injection, Water-Cooled Diesel Engine No. of Cylinders 3 3 Displacement 80.43 in³ 67.2 in³ Rated Engine Speed 2600 rpm 3000 rpm Engine Power (Gross) 26 hp 25.3 hp PTO Power 23 hp 19.2 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled, pressurized, thermostat controlled bypass, impeller pump Water-Cooled Air Cleaner Dry type with double filter Not Published Fuel System Indirect injection; Bosch M type ND-PFR (Denso) injection pump, throttle type injectors Indirect Injection Alternator 50 A 55 A, 12 V ▶ HydraulicsPump Type Gear type, front mounted, engine driven Not Published Implement Flow 7.8 gpm 7.6 gpm Steering Flow 3.4 gpm 3.8 gpm Total Hydraulic Flow 11.2 gpm (7.8 + 3.4, computed) 11.2 gpm Overall Hydraulic Pump Flow Not Published 11.2 gpm Hydraulic System Type Open center Open Center, full-live hydraulic with position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 Single or dual ▶ Fluid CapacityFuel Tank Capacity Not Published 6.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent (3016 Gear Drive); Live (3016 Hydrostatic Drive) Independent Wet Clutch PTO Rear 540 rpm @ 2376 rpm 540 rpm @ 2837 rpm Mid-PTO Availability Optional; 2000 rpm @ 2525 rpm Optional; 2500 rpm @ 2837 rpm Category, 3-Point Hitch CAT I CAT I with check chains Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 1720 lb 771 lb Lift Control Type Position control Position Control ▶ Transmission & DrivetrainTransmission Type Synchro shuttle, constant mesh main with 2 ranges (3016 Gear Drive); Hydrostatic, 3 ranges (3016 Hydrostatic Drive) HST - 2 Range No. of Speeds 8F/8R (3016 Gear Drive); Infinite, 3 ranges (3016 Hydrostatic Drive) Infinite forward and reverse (2 ranges) Max Travel Speed (Forward) 11.9 mph (3016 Gear Drive); 13.8 mph (3016 Hydrostatic Drive) 7.3 mph Max Travel Speed (Reverse) 9.9 mph (3016 Gear Drive); 6.9 mph (3016 Hydrostatic Drive) Not Published Clutch Dry single disc, diaphragm type, 8.46 in Not Published Differential Lock & Limited Slip Options Mechanical differential lock, pedal actuated Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Wet disc, mechanical Single Pedal Seat Suspension & Adjustability Not Published Not Published Front Axle Type Mechanical front drive (MFD), spiral bevel gear differential with bevel gear reductions Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 969 lbf Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121.3 in 100.4 in Overall Width 63 in 46.3 in Wheelbase 67.3 in 55.1 in Ground Clearance 11.4 in 6.7 in Min. Turn Radius without Brakes 7.9 ft (with brake applied) 7.2 ft (with brake applied) Height to Top of ROPS 81.5 in 86.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2437 lb (3016 Gear Drive); 2459 lb (3016 Hydrostatic Drive) 1620 lb Weight with ROPS and Loader Not Published 2026 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R3 Turf, R4 Industrial R1 Agricultural - Front 7x16 Not Published R1 Agricultural - Rear 11.2x24 Not Published R3 Turf - Front 25x8.5-14 18x8.5-10 R3 Turf - Rear 13.6x16 26x12-12 R4 Industrial - Front 27x8.50-15 18x8.5-10 R4 Industrial - Rear 15x19.5 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published L11: Front loader skid-steer couplers for superfast hookups Loader Model ML115 L11 Loader Lift Height ML115: 99 in L11: 68 in Loader Lift Capacity (Full Height) ML115: 1,650 lb L11: 794 lb Loader Breakout Force ML115: 2,650 lb L11: 1433 lb ▶ WarrantyWarranty Length & Coverage Not Published 7-Year Limited Powertrain Warranty
