▶ EngineEngine Manufacturer Mahindra Mahindra Engine Model Not Published MDI 2700 R2 Engine Type Four stroke, direct injection, water-cooled diesel Four-stroke, direct-injection water-cooled, diesel No. of Cylinders 3 4 Displacement 161.7 in³ 166.7 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 43 hp 41 hp PTO Power 34.9 hp 31 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Water-cooled Air Cleaner Not Published Not Published Fuel System Not Published Direct injection Alternator 45 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 10.9 gpm 8.7 gpm Steering Flow 5 gpm 5.8 gpm Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center, full-live hydraulic with position and draft controls Open center, full-live hydraulic with position and draft controls Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 None standard (1 spool optional) No. of Optional Remote Valves 1 (optional) 1 spool ▶ Fluid CapacityFuel Tank Capacity 12 gal 14.55 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm @ 2058 rpm 540 rpm @ 2058 engine rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 1 and 2 with telescopic stabilizers Category I & II adjustable, with telescopic stabilizers Hitch Lift Capacity 3969 lb 3525 lb Hitch Lift Capacity (at 24”) Not Published Not Published Lift Control Type Position and draft control Position & draft control ▶ Transmission & DrivetrainTransmission Type Forward/reverse synchro shuttle with synchro speeds and constant mesh range Sliding mesh No. of Speeds 8F/8R 8F / 2R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dual dry with cerametallic lining Dual Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power Hydrostatic power steering Brakes Dry disc Fully enclosed dry disc Seat Suspension & Adjustability Not Published mComfort mechanical suspension seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 134 in 115.3 in Overall Width 72.5 in 69.4 in Wheelbase Not Published Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 10.8 ft 9.7 ft (with brake applied) Height to Top of ROPS 93.3 in 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 5567 lb 4191 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural R1 Agricultural - Front 9.5x20 6X16 R1 Agricultural - Rear 13.6x28 12.4X28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 10.5/80x18 Not Published R4 Industrial - Rear 16.9x24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer style quick-attach coupler Loader Model 5545L 4550-2L Loader Lift Height 5545L: 120 in 4550-2L: 116.6 in Loader Lift Capacity (Full Height) 5545L: 2950 lb 4550-2L: 2,866 lb at pivot pins to full height Loader Breakout Force 5545L: 4950 lb 4550-2L: 4,978 lb at pivot pins ▶ WarrantyWarranty Length & Coverage Not Published 7-Year Limited Powertrain Warranty
