▶ EngineEngine Manufacturer Mahindra Kubota Engine Model VNEM 373 V3307-CR-TE4 Engine Type Turbocharged and intercooled, common-rail, liquid-cooled diesel (Tier 4 Final) Liquid-cooled, diesel, 4-cylinder No. of Cylinders 3 4 Displacement 161.7 in³ 203 in³ Rated Engine Speed 2100 rpm 2400 rpm Engine Power (Gross) 71 hp 71.1 hp PTO Power 61 hp 60 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Dual element (primary and secondary elements) Fuel System Common rail direct injection Common Rail System (CRS) Alternator Power Shuttle: 55 A; Power Shuttle Cab: 140 A 130 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 11.1 gpm 16.7 gpm Steering Flow 4.6 gpm 6.3 gpm Total Hydraulic Flow 15.7 gpm 23.0 gpm (16.7 gpm implement + 6.3 gpm steering, computed) Overall Hydraulic Pump Flow 15.7 gpm 23.0 gpm (16.7 + 6.3, computed) Hydraulic System Type Open center, position and draft control, telescoping stabilizers and flex links Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Double auxiliary valves 2 (SCD / FD) No. of Optional Remote Valves 3rd valve Max. 3 ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 23.8 gal Coolant Capacity Not Published 10.6 qt Crankcase Capacity Not Published 12.7 qt Transmission / Hydraulic System Capacity Not Published 49.6 qt Front Axle Fluid Capacity Not Published 5.8 qt (front differential case) plus 3.7 qt (front axle gear case) ▶ PTO & HitchPTO Type 2 speed independent push button type 1 PTO (wet clutch) Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 @ 1993 rpm and 540E @ 1469 rpm 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch CAT I & II I / II Hitch Lift Capacity Not Published 4,189 lb Hitch Lift Capacity (at 24”) 5,952 lb 3,307 lb Lift Control Type Position and draft control Position, draft (top link sensing) & mixed control ▶ Transmission & DrivetrainTransmission Type Full synchro mesh speed and constant mesh range Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) No. of Speeds 15F / 15R F12/R12 (option: F18/R18 with creep) Max Travel Speed (Forward) 21.4 mph 24.9 mph Max Travel Speed (Reverse) Not Published 24.7 mph Clutch Power shuttle with wet clutch and torsional damper Multiple wet disc Differential Lock & Limited Slip Options Not Published Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Ultra Grand Cab II Steering Hydrostatic power steering with tiltable steering column Hydrostatic power steering Brakes Oil immersed brakes, lever actuated parking brake Hydraulic wet disc Seat Suspension & Adjustability mComfort seat with contoured cushions, armrests and adjustable legroom; air-ride suspension seat in cab Mechanical-suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air-suspension seat Front Axle Type Not Published Bevel gear type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 82 in 75.6 in Wheelbase 87.4 in 84.1 in Ground Clearance 15.5 in 18.1 in (front axle crop clearance) Min. Turn Radius without Brakes 12.5 ft (3.8 m) 11.8 ft Height to Top of ROPS 106 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 115 in 101 in Overall Length 152.7 in 144 in ▶ WeightTractor Weight (Base) 6,548 lb (6075 Power Shuttle); 7,495 lb (6075 Power Shuttle Cab) 6,008 lb Weight with ROPS and Loader 8,428 lb (6,548 + 1,880, computed; 1,604.8 gal loader shipping weight) Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural, Industrial Standard: 320/70R24 front, 420/75R34 rear R1 Agricultural - Front 11.2 x 24 320/70R24 R1 Agricultural - Rear 16.9 x 30 420/75R34 R3 Turf - Front Not Published 9.50-24 R3 Turf - Rear Not Published 18.4-26 R4 Industrial - Front 43 x 16-20 14-17.5 R4 Industrial - Rear 18.4-28 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer tool carrier system for ultra-fast attachments hookup LA1154A: 2-Lever Quick Coupler Loader Model 6075L LA1154A Loader Lift Height Loader 6075L: 133 in LA1154A: Height position: 133.0 in; Power position: 117.6 in Loader Lift Capacity (Full Height) Loader 6075L: 3,609 lb (at pivot pin) LA1154A: Height position: 2,674 lb; Power position: 2,928 lb Loader Breakout Force Loader 6075L: 5,000 lb LA1154A: Height position: 4,079 lbf; Power position: 5,128 lbf ▶ WarrantyWarranty Length & Coverage 5-year limited powertrain warranty Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
