▶ EngineEngine Manufacturer Mahindra John Deere Engine Model NE 479 TCI PowerTech 4045 PWL Engine Type Four Stroke, Turbo Charged, Intercooled, Direct Injection, Water Cooled Diesel Engine 4-cylinder in-line turbocharged and aftercooled diesel, electronic fuel control No. of Cylinders 4 4 Displacement 203.2 in³ 275 in³ Rated Engine Speed 2300 rpm 2400 rpm Engine Power (Gross) 83 hp 90 hp PTO Power 70 hp 76.7 hp Engine Emissions Constraints Tier 3 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Dry type with safety cartridge & dust unloader valve Dry type with safety element Fuel System Rotary FIP with KSB Unit MICO (BOSCH) High pressure common rail, electronic fuel control Alternator 55 A, 12 V 90 A ▶ HydraulicsPump Type Independent fully 'live' hydraulic pump Tandem gear pump, two engine-mounted pumps Implement Flow 17 gpm 15.9 gpm Steering Flow 5.3 gpm 6.6 gpm Total Hydraulic Flow 22.3 gpm 22.5 gpm Overall Hydraulic Pump Flow Not Published 22.5 gpm Hydraulic System Type Independent fully live hydraulic pump with Vary-Touch draft and position controls Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 rear; 0 mid No. of Optional Remote Valves Not Published 3 rear; up to 3 mid ▶ Fluid CapacityFuel Tank Capacity 19.28 gal 25 gal (open operator station); 30 gal (cab) Coolant Capacity 2.58 gal 2.5 gal (open operator station and low-profile); 3 gal (cab) Crankcase Capacity 9.48 qt 3.2 gal Transmission / Hydraulic System Capacity 8.59 gal 11.5 gal Front Axle Fluid Capacity 1.79 gal 1.3 gal (MFWD differential housing); 0.74 qt (each wheel hub) ▶ PTO & HitchPTO Type Rear independent PTO shaft Independent, electro-hydraulic engagement, wet PTO clutch PTO Rear Not Published 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II ball joints with adjustable outside lateral stabilizer Category 2, convertible to Category 1 Hitch Lift Capacity 5500 lb 5159 lb (maximum lift force at hitch ball); 3846 lb throughout lift range Hitch Lift Capacity (at 24”) 3850 lb 4630 lb (electrohydraulic hitch) Lift Control Type Position and draft control Electrohydraulic (EH) hitch with electronic quick raise-lower (premium cab); top-link draft sensing ▶ Transmission & DrivetrainTransmission Type Not Published PowrReverser 12F/12R standard; PowrReverser Hi-Lo 24F/12R optional No. of Speeds 12F / 12R 12 forward, 12 reverse (standard); 24 forward, 12 reverse (Hi-Lo) Max Travel Speed (Forward) Not Published 21.7 mph (electronically limited; 12/12 transmission, 460/85R30 rear tires) Max Travel Speed (Reverse) Not Published 21.7 mph (electronically limited; C-4 reverse calculates to 23.8 mph) Clutch Dry Dual Clutch (normally disengaged PTO clutch) Wet Differential Lock & Limited Slip Options Not Published Rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS (open operator station); standard or premium cab; MFWD Steering Hydrostatic (Power Steering) Hydrostatic power steering Brakes Oil immersed, foot operated, independent with interlock for simultaneous operation; hand brake for parking Hydraulic wet disk, self-equalizing and self-adjusting, dual stage Seat Suspension & Adjustability Not Published Mechanical seat standard; air-suspension seat optional for cab Front Axle Type Not Published MFWD Front Axle Rating Not Published 6615 lb (max front axle load); 13230 lb (max rear axle load); 11510 lb (max permissible weight) Drawbar Capacity Not Published 2755 lb (standard drawbar, 9.8 in extended); 2425 lb (standard, 350 and 15.7 in extended); 3195 lb (heavy duty, 9.8 in); 2645 lb (heavy duty, 350 and 15.7 in) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 162.04 in 159.13 in Overall Width 77.3 in 83.6 in (minimum, 16.9-30 R1 tires); 85.1 in (minimum, 18.4-30 R1 tires) Wheelbase 2WD: 85.31 in; 4WD: 85.8 in 92.5 in Ground Clearance Not Published 17 in (front axle) Min. Turn Radius without Brakes 2WD: 157 in; 4WD: 180 in 11.6 ft (MFWD) Height to Top of ROPS 2WD: 89.5 in; 4WD: 94.5 in 101.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 102.4 in ▶ WeightTractor Weight (Base) 2WD: 6878 lb; 4WD: 7297 lb 7275 lb (MFWD open operator station); 8150 lb (MFWD cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 18.4-30 R1 bias rear standard; 16.9-30 R1 also listed R1 Agricultural - Front Not Published 12.4-24 R1 Agricultural - Rear Not Published 18.4-30 R1 bias R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach option with integrated parking stand (520M and 540M MSL or NSL) Loader Model Not Published 520M (NSL and MSL); 540M (NSL) Loader Lift Height Not Published 520M NSL: 133 in; 520M MSL: 133 in Loader Lift Capacity (Full Height) Not Published 520M NSL: 3644 lb; 520M MSL: 2687 lb (to maximum height at pivot point) Loader Breakout Force Not Published 520M NSL: 4511 lbf; 520M MSL: 4691 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Not Published 5-year / 2,000-hour powertrain warranty (whichever comes first), as sold new
