▶ EngineEngine Manufacturer Kukje Yanmar Engine Model A1100N3 3TNV76F Engine Type Four-stroke, naturally aspirated, indirect injection, water-cooled diesel 3-cylinder, indirect injection (swirl chamber), water-cooled No. of Cylinders 3 3 Displacement 71.7 in³ 68.0 in³ Rated Engine Speed 2600 rpm 3000 rpm Engine Power (Gross) 22 hp 21.5 hp PTO Power 14.9 hp 15 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Not Published Dry Fuel System Indirect Injection In-line injection pump Alternator 50 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump, transmission driven Implement Flow 4.5 gpm 4.6 gpm Steering Flow Not Published 2.1 gpm Total Hydraulic Flow 7.1 gpm 6.7 gpm Overall Hydraulic Pump Flow 7.1 gpm 6.7 gpm Hydraulic System Type Open Center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Not Published 1 set (2 quick couplers, optional) ▶ Fluid CapacityFuel Tank Capacity 5.8 gal 6.6 gal Coolant Capacity 3.7 qt 0.9 gal Crankcase Capacity 2.3 qt 0.8 gal Transmission / Hydraulic System Capacity Not Published 3.0 gal (3.4 gal with front-end loader; 4.7 gal with front-end loader and backhoe) Front Axle Fluid Capacity Not Published 0.5 gal ▶ PTO & HitchPTO Type Independent Independent (electro-hydraulic) PTO Rear 540 @ 2550 rpm Standard (540 rpm) Mid-PTO Availability Available; 2000 @ 2550 rpm Standard (2,500 rpm) Category, 3-Point Hitch CAT I with Check Chains Category I Hitch Lift Capacity 1,323 lb 992 lb Hitch Lift Capacity (at 24”) Not Published 728 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type HST - 2 range Hydrostatic Drive No. of Speeds Infinite 2 ranges Max Travel Speed (Forward) Not Published 8.70 mph Max Travel Speed (Reverse) Not Published 5.22 mph Clutch Dry-Single N/A Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet Disc Wet, multi-disc Seat Suspension & Adjustability Not Published High-back seat, folding armrest, retractable seat belt, fore-aft adjustment Front Axle Type Not Published Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Hitch: 882 lb vertical, 3,527 lb horizontal; drawbar with clevis: 772 lb vertical, 3,527 lb horizontal ▶ Dimensions & ManeuverabilityOverall Width 45.8 in 47 in Wheelbase 57.5 in 56 in Ground Clearance 9.4 in Not Published Min. Turn Radius without Brakes 7.2 ft 7.87 ft Height to Top of ROPS 91.3 in 87 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published Overall Length 100.5 in 97 in (bumper to link) ▶ WeightTractor Weight (Base) 1,638 lb 1,433 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Front 18x8.50-10, rear 26x12.0-12; offered in industrial or turf R1 Agricultural - Front 6x12 Not Published R1 Agricultural - Rear 9.5x16 Not Published R3 Turf - Front 20x8-10 18x8.50-10 R3 Turf - Rear 29x12.5-15 26x12.0-12 R4 Industrial - Front 20x8-10 18x8.50-10 R4 Industrial - Rear 27x12.5-15 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System 25LSK: Skid steer style quick coupler, standard LL1102: quick attachment (ISO 24410 attachments only), latch handle with latch pin Loader Model 25LSK LL1102; LL1700; LL1001 Loader Lift Height 25LSK: 75.3 in LL1001: 72.6 in (at pivot pin) Loader Lift Capacity (Full Height) 25LSK: 900 lb LL1001: 902 lb (at pivot pin, maximum height) Loader Breakout Force 25LSK: 2,000 lb LL1001: 1,836 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published 6-year limited warranty
