▶ EngineEngine Manufacturer Iseki Yanmar Engine Model Not Published n/a Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 91.4 in³ 76.9 in³ Rated Engine Speed 2600 rpm 3000 rpm Engine Power (Gross) 24.8 hp 24.7 hp PTO Power 20.1 hp 17.2 hp Engine Emissions Constraints Tier 4 Tier 4B Final Cooling System Type Liquid cooled Pressurized liquid with recirculating bypass Air Cleaner Not Published Not Published Fuel System Not Published In-line injection pump Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow 5.5 gpm 4.6 gpm Steering Flow 3.2 gpm 2.1 gpm Total Hydraulic Flow 8.7 gpm 6.7 gpm Overall Hydraulic Pump Flow 8.7 gpm 6.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 5.5 gpm Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 7.1 gal 6.6 gal Coolant Capacity Not Published 3.5 qt Crankcase Capacity Not Published 3.0 qt Transmission / Hydraulic System Capacity Not Published 3.0 gal Front Axle Fluid Capacity Not Published 0.5 gal ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Independent, 2000 rpm (optional) Standard (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,322 lb 992 lb at ball ends Hitch Lift Capacity (at 24”) 992 lb 728 lb Lift Control Type Position control Lift-hold-lower ▶ Transmission & DrivetrainTransmission Type Hydrostatic 2-Range Hydrostatic / Dual Pedal No. of Speeds Infinite forward and reverse (3-range) Infinite (2-range) Max Travel Speed (Forward) Not Published 9.1 mph Max Travel Speed (Reverse) Not Published 5.5 mph Clutch Not Published Not Applicable Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical, foot-operated rear diff lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Central support, bevel gear type Brakes Wet, multiple disc Wet, multi-disc Seat Suspension & Adjustability Adjustable mechanical suspension Not Published Front Axle Type Not Published 4WD (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 111 in 97.4 in Overall Width 55.1 in 46.7 in Wheelbase 61.4 in 56.1 in Ground Clearance 11.6 in 12 in Min. Turn Radius without Brakes Not Published 94 in Height to Top of ROPS 96.1 in 90 in Height to Top of ROPS (folded) Not Published 64 in Height to Top of Cab Model Not Published 87.4 in ▶ WeightTractor Weight (Base) 2,077 lb n/a Weight with ROPS and Loader Not Published 1,444 lb (ROPS tractor only) Weight with Cab and Loader Not Published 1,805 lb (Cab tractor only) ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R3 Turf, R4 Industrial R1 Agricultural - Front 7-12 Not Applicable R1 Agricultural - Rear 35x12.00-16.5 or 9.5-16 Not Applicable R3 Turf - Front 25x8.50-14 18X8.50-10 R3 Turf - Rear 36x13.50-15 26X12.0-12 R4 Industrial - Front 25x8.50-14 18X8.50-10 R4 Industrial - Rear 14-17 26X12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 100LC: Quick Mount system (no tools) Loader Model FLx2106 n/a Loader Lift Height FLx2106: 83 in 72 in Loader Lift Capacity (Full Height) Not Published 1,005 lb Loader Breakout Force Not Published 2,078 lb ▶ WarrantyWarranty Length & Coverage Not Published 6-year limited warranty (2-year bumper-to-bumper + 4-year powertrain)
