▶ EngineEngine Manufacturer Iseki Yanmar Engine Model Not Published 3TNV88-BMJT Engine Type 3-cylinder liquid-cooled diesel 3-cylinder liquid-cooled diesel, direct injection No. of Cylinders 3 3 Displacement 91.4 in³ 100.1 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 33 hp 32.4 hp PTO Power Gear: 26 hp; HST: 24.5 hp 25 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry type with safety element Fuel System Not Published Direct injection, self bleeding, in-line fuel pump with electric shutoff Alternator Not Published 40 A ▶ HydraulicsPump Type Not Published Dual tandem gear pump Implement Flow 9.1 gpm 8.6 gpm Steering Flow SynchroShuttle: 4.9 gpm; HST and PowerShuttle: 6 gpm 5.3 gpm Total Hydraulic Flow SynchroShuttle: 14.0 gpm; HST and PowerShuttle: 15.1 gpm 13.9 gpm Overall Hydraulic Pump Flow Not Published 13.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 9.1 gpm Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 2 spool optional Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 13.5 gal (open station); 11.8 gal (cab) Coolant Capacity 7.1 qt 5.6 qt (open station); 7.4 qt (cab) Crankcase Capacity 5 qt 5.1 qt Transmission / Hydraulic System Capacity 32.8 qt 6.8 gal (eHydro); 6.3 gal (PowrReverser) Front Axle Fluid Capacity 7.9 qt 1.2 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic control Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Optional, 2100 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity 2,800 lb Not Published Hitch Lift Capacity (at 24”) Not Published 2200 lb Lift Control Type Position control with rate of drop control Position control ▶ Transmission & DrivetrainTransmission Type 8x8 SynchroShuttle (platform only), 12x12 PowerShuttle, or 3-range hydrostatic with cruise (platform only) eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) No. of Speeds Not Published Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) Not Published 19 mph (eHydro); 16.4 mph (PowrReverser) Max Travel Speed (Reverse) Not Published 19 mph (eHydro); 16.4 mph (PowrReverser) Clutch Wet multi-disc (PowerShuttle) Multiple stage wet disc, 4.4 in (PowrReverser) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Semi-flat isolated platform, folding ROPS Two-post folding ROPS; cab optional; MFWD standard Steering Power steering Hydrostatic power steering Brakes Wet disc Wet disk Seat Suspension & Adjustability Adjustable suspension seat with retractable seat belt and adjustable armrest Not Published Front Axle Type 4WD front axle, push-pull engagement lever Mechanical front wheel drive (MFWD), standard, all ranges Front Axle Rating Not Published 1587 to 3197 lb Drawbar Capacity Not Published 562 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121.0 in 120.2 in Overall Width 62.0 in 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) Wheelbase 70.0 in 68 in Ground Clearance 14.0 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 87.4 in 93.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 89.4 in ▶ WeightTractor Weight (Base) Platform: 3,025 lb; Cab: 3,384 lb 2900 lb (open station); 3570 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear (LSW305 R343 / LSW610 R470 optional); industrial: 10-16.5 front, 14.9-24 rear (also 25x8.5-14 front, 15x19.5 rear) R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Agricultural - Front 8-16 7.00-14 R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 11.2-24 R3 Turf - Front 27x8.50-15 (LSW305 R343 optional) 27x8.50-15 R3 Turf - Rear 41x14.00-20 (LSW610 R470 optional) 41x14.00-20 R4 Industrial - Front 10-16.5 or 25x8.5-14 25x8.50-14 or 27x8.50-15 R4 Industrial - Rear 14.9-24 or 15x19.5 43x16.00-20 or 15.00-19.5 ▶ Loader & AttachmentsQuick Attach Loader System DL120: pin-type or skid-steer quick attach John Deere quick-attach (Quik-Park); skid-steer style carrier optional on 300CX Loader Model DL120 300X; 300CX; H160; H165; 300R; 320R Loader Lift Height DL120: 102 in 300X: 90 in; 300CX: 102 in; H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in Loader Lift Capacity (Full Height) DL120: 1,900 lb 300X: 1360 lb; 300CX: 1598 lb; H160: 1360 lb; H165: 1598 lb; 300R: 1360 lb; 320R: 1598 lb (to maximum height at pivot pin) Loader Breakout Force Not Published 300X: 2855 lbf; 300CX: 3327 lbf; H160: 2855 lbf; H165: 3327 lbf; 300R: 2855 lbf; 320R: 3327 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 2-year/2,000-hour all-inclusive; 3-year/2,000-hour engine and powertrain Not Published
