▶ EngineEngine Manufacturer Iseki Kubota Engine Model Not Published D1803-CR-E5 Engine Type 3-cylinder liquid-cooled diesel Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 3 3 Displacement 91.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 33 hp 33 hp PTO Power Gear: 26 hp; HST: 24.5 hp 26.1 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry Dry type, single element Fuel System Not Published Direct injection Alternator Not Published 45 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.1 gpm 6.3 gpm Steering Flow SynchroShuttle: 4.9 gpm; HST and PowerShuttle: 6 gpm 3.8 gpm Total Hydraulic Flow SynchroShuttle: 14.0 gpm; HST and PowerShuttle: 15.1 gpm 10.1 gpm (6.3 + 3.8, computed) Overall Hydraulic Pump Flow Not Published 10.1 gpm (6.3 + 3.8, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 9.1 gpm Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 2 spool optional Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 11.1 gal Coolant Capacity 7.1 qt 6.3 qt Crankcase Capacity 5 qt 7.1 qt Transmission / Hydraulic System Capacity 32.8 qt 6.9 gal Front Axle Fluid Capacity 7.9 qt 4.8 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic control Live independent PTO with hydraulic clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 2,800 lb 1998 lb Hitch Lift Capacity (at 24”) Not Published 1435 lb Lift Control Type Position control with rate of drop control Position control ▶ Transmission & DrivetrainTransmission Type 8x8 SynchroShuttle (platform only), 12x12 PowerShuttle, or 3-range hydrostatic with cruise (platform only) Hydrostatic transmission (3-range) No. of Speeds Not Published 3-range Max Travel Speed (Forward) Not Published 14.1 mph Max Travel Speed (Reverse) Not Published 12.7 mph Clutch Wet multi-disc (PowerShuttle) Not Applicable Differential Lock & Limited Slip Options Not Published Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Semi-flat isolated platform, folding ROPS Not Published Steering Power steering Integral type power steering Brakes Wet disc Mechanical, wet disc type Seat Suspension & Adjustability Adjustable suspension seat with retractable seat belt and adjustable armrest Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type 4WD front axle, push-pull engagement lever Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 730 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121.0 in 108.5 in (without 3-point hitch) Overall Width 62.0 in 55.1 in Wheelbase 70.0 in 63.4 in Ground Clearance 14.0 in 13.4 in Min. Turn Radius without Brakes Not Published 8.2 ft (with brake applied) Height to Top of ROPS 87.4 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Platform: 3,025 lb; Cab: 3,384 lb 2778 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear (LSW305 R343 / LSW610 R470 optional); industrial: 10-16.5 front, 14.9-24 rear (also 25x8.5-14 front, 15x19.5 rear) R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 8-16 7.2-16 R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 11.2-24 R3 Turf - Front 27x8.50-15 (LSW305 R343 optional) 25X8.50-14 R3 Turf - Rear 41x14.00-20 (LSW610 R470 optional) 13.6-16 R4 Industrial - Front 10-16.5 or 25x8.5-14 27X8.50-15 R4 Industrial - Rear 14.9-24 or 15x19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System DL120: pin-type or skid-steer quick attach Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Loader Model DL120 LA526 Loader Lift Height DL120: 102 in 94.8 in Loader Lift Capacity (Full Height) DL120: 1,900 lb 1144.4 lb Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage 2-year/2,000-hour all-inclusive; 3-year/2,000-hour engine and powertrain Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
