▶ EngineEngine Manufacturer Shibaura Yanmar Engine Model N843T-F 3TNV88C-KJPT Engine Type 3-cylinder diesel, liquid-cooled, turbocharged 4-cycle, inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 91.5 in³ 100.2 in³ Rated Engine Speed 2600 rpm 2800 rpm Engine Power (Gross) 34 hp 34.2 hp PTO Power Gear: 29 hp; HST: 27.2 hp 30.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid Air Cleaner Not Published Dry Fuel System Turbocharged, indirect low-pressure injection Direct injection Alternator Not Published 55 A, 12 V ▶ HydraulicsPump Type Gear-type pump 2 single-section external gear pumps, 1 on each side of the engine timing-gear cover Implement Flow Not Published 5.9 gpm Steering Flow 3.8 gpm 4.4 gpm Total Hydraulic Flow 10.5 gpm 10.3 gpm Overall Hydraulic Pump Flow Not Published 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 6.7 gpm Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Up to 2 Up to two (optional) ▶ Fluid CapacityFuel Tank Capacity 10.04 gal 9.7 gal Coolant Capacity 1.32 gal 1.2 gal Crankcase Capacity 1.22 gal 1.1 gal Transmission / Hydraulic System Capacity 10.04 gal 9.2 gal Front Axle Fluid Capacity 1.48 gal 1.0 gal ▶ PTO & HitchPTO Type Not Published Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,205 lb Not Published Hitch Lift Capacity (at 24”) 1,600 lb 1,670 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type 9 x 3 mechanical shift constant mesh gears or 3-range hydrostatic 8F/8R synchromesh shuttle shift gear transmission No. of Speeds Gear: 9F / 3R; HST: 3-range infinite 8F/8R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Gear: dry single disc Single dry traction clutch Differential Lock & Limited Slip Options Mechanical engagement via heel pedal Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Internal wet brakes, single brake pedal on HST, two brake pedals on gear models Wet disk Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt, fixed steering wheel Not Published Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives MFWD (4WD) Front Axle Rating Not Published 1,940 lb Drawbar Capacity Not Published 1,102 lb (static vertical load) ▶ Dimensions & ManeuverabilityOverall Width 52.4 in 57.3 in Wheelbase 65.9 in 62 in Ground Clearance Not Published 14 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brake applied) Height to Top of ROPS 97.6 in Not Published Height to Top of ROPS (folded) 63.8 in Not Published Height to Top of Cab Model Not Published Not Published Overall Length 116 in (without 3-point hitch) 111.2 in ▶ WeightTractor Weight (Base) Gear: 2,734 lb; HST: 2,767 lb 2,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 7-14 R1 Agricultural - Rear Not Published 11.2-24 R3 Turf - Front 27x8.50-15 27X8.5-15 R3 Turf - Rear 38x14.00-20 41X14-20 R4 Industrial - Front 27x8.50-15 25X8.5-14 R4 Industrial - Rear 15x19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System FLx2407: skid steer or pin-type implement attachments Quick-change attachment carrier Loader Model FLx2407 300E Loader Lift Height FLx2407: 94.3 in (at pivot pin) 84 in (at pivot pin) Loader Lift Capacity (Full Height) FLx2407: 1,450 lb (at pivot pin, full height) 1,186 lb (at pivot pin) Loader Breakout Force FLx2407: 2,288 lb (at pivot pin) 1,704 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours
