▶ EngineEngine Manufacturer Mitsubishi Shibaura Engine Model K38 N3LDI-T Engine Type 3-cylinder turbocharged and intercooled diesel 3-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 3 3 Displacement 101 in³ 101.4 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 36.2 hp 36.2 hp PTO Power Gear: 27.5 hp; HST: 26.3 hp 27.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Common rail direct injection with electronic engine management Common rail direct injection Alternator Not Published Not Published ▶ HydraulicsPump Type Engine-driven gear-type pump Engine-driven gear-type pump Implement Flow 11.6 gpm 11.0 gpm Steering Flow 6.8 gpm Not Published Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.6 gpm 12.1 gpm No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 10.56 gal Coolant Capacity Not Published 6.34 qt Crankcase Capacity Not Published 4.86 qt Transmission / Hydraulic System Capacity Not Published 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal Front Axle Fluid Capacity Not Published 7.9 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged Independent, with soft-start feature PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Optional, 2000 rpm Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I with extendable ball ends Hitch Lift Capacity Not Published 2,646 lb Hitch Lift Capacity (at 24”) 2,535 lb 2,535 lb Lift Control Type Position control; draft control optional Position and draft control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds Power shuttle: 12F / 12R; Servo-HST: 3-range infinite 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-disc (power shuttle) Single stage dry type Differential Lock & Limited Slip Options Mechanical rear differential lock, right side heel pedal Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Drop-axle rear with bull gear final drives Not Published Steering Power steering, tilt steering wheel Power steering Brakes Internal wet disc brakes, individual control via independent foot pedals Internal wet disc brakes, individual control via independent foot pedals Seat Suspension & Adjustability Deluxe suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 122.0 in 122.0 in Overall Width 64.2 in 64.2 in Wheelbase 69.7 in 69.7 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 99.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91.3 in 91.3 in ▶ WeightTractor Weight (Base) ROPS: 3,362 lb; Cab: 3,803 lb 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 8-16 front, 12.4-24 rear (13.6-24 optional); turf: 27x8.50-15 front, 41x14.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/75R16 front, 400/80R24 rear) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 8-16 R1 Agricultural - Rear 12.4-24 (13.6-24 optional) 12.4x24 R3 Turf - Front 27x8.50-15 27x8.50-15 R3 Turf - Rear 41x14.00-20 41x14.00-20 R4 Industrial - Front 10-16.5 or 250/75R16 10-16.5 R4 Industrial - Rear 17.5L-24 or 400/80R24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System DL125: universal skid steer or compact quick-attach tool carrier DL125: Pin-on (skid steer quick attach optional) Loader Model DL125 DL125 Loader Lift Height DL125: 102.4 in DL125: 106 in Loader Lift Capacity (Full Height) DL125: 1,840 lb DL125: 1,660 lb Loader Breakout Force DL125: 2,190 lb DL125: 3,000 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
