▶ EngineEngine Manufacturer Mitsubishi FPT Engine Model K39 S8000 Engine Type 4-cylinder turbocharged and intercooled diesel 3-cylinder, FPT turbocharged & aftercooled diesel, Tier 4 B/Final No. of Cylinders 4 3 Displacement 134.7 in³ 178.8 in³ Rated Engine Speed 2500 rpm 2300 rpm Engine Power (Gross) 53.6 hp 54 hp PTO Power Gear: 42.1 hp; HST: 40.9 hp 40 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Common rail direct injection with electronic engine management Electronic high pressure common rail Alternator Not Published 120 A ▶ HydraulicsPump Type Engine-driven gear-type pump Fixed displacement Implement Flow 11.6 gpm 12.6 gpm Steering Flow 6.8 gpm Not Published Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 11.6 gpm Not Published No. of Standard Remote Valves 1 2 No. of Optional Remote Valves Up to 3 3 ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 21.7 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged Independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540 (standard); 540/540E (optional) Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category I Category I/II Hitch Lift Capacity Not Published 5,952 lb (optional hitch 6,614 lb) Hitch Lift Capacity (at 24”) 3,086 lb 4,300 lb (optional hitch 4,740 lb) Lift Control Type Position control; draft control optional Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle (4 gears, 3 ranges) or 3-range electronic Servo-HST MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 power shuttle (wet clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) No. of Speeds Power shuttle: 12F / 12R; Servo-HST: 3-range infinite MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper Max Travel Speed (Forward) Not Published 18.6 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-disc (power shuttle) MFD: wet clutch (12x12 power shuttle); 2WD: wet clutch (8x8 power shuttle); optional dry clutch (12x12 mechanical shuttle) Differential Lock & Limited Slip Options Mechanical rear differential lock, right side heel pedal Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Drop-axle rear with bull gear final drives Not Published Steering Power steering, tilt steering wheel Hydrostatic Brakes Internal wet disc brakes, individual control via independent foot pedals Wet disc Seat Suspension & Adjustability Deluxe suspended seat with armrests and seat belt (vinyl on ROPS, cloth on cab) Mechanical contoured seat, adjustable; optional air-ride seat Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.3 in 155.3 in Overall Width 65.4 in Not Published Wheelbase 77.2 in 2WD: 82.1 in; MFD: 83.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.9 in 2WD: 98 in; MFD: 100 in ▶ WeightTractor Weight (Base) ROPS: 4,145 lb; Cab: 4,575 lb 2WD Cab: 6,173 lb; 2WD Non-cab: 5,622 lb; MFD Cab: 6,834 lb; MFD Non-cab: 6,283 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 9.5x16 front, 13.6x28 rear (16.9x24 optional); turf: 27x10.50-15 front, 44x18.00-20 rear; industrial: 10-16.5 front, 17.5L-24 rear (also 250/80R16 front, 360/80R28 rear) R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial R1 Agricultural - Front 9.5-16 2WD: 9.5L-15; MFD: 11.2x24 R1 Agricultural - Rear 13.6-28 (16.9-24 optional) 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) R3 Turf - Front 27x10.50-15 Not Published R3 Turf - Rear 44x18.00-20 Not Published R4 Industrial - Front 10-16.5 or 250/80R16 Not Published R4 Industrial - Rear 17.5L-24 or 360/80R28 Not Published ▶ Loader & AttachmentsQuick Attach Loader System DL135: universal skid steer or compact quick-attach tool carrier Not Published Loader Model DL135 L610 Loader Lift Height DL135: 110.2 in 130.3 in Loader Lift Capacity (Full Height) DL135: 2,420 lb NSL: 1,828 lb; MSL: 3,153 lb Loader Breakout Force DL135: 2,860 lb Not Published ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
