▶ EngineEngine Manufacturer Shibaura John Deere Engine Model Shibaura N4LDI-TA Not Published Engine Type 4-cylinder turbocharged intercooled diesel, liquid-cooled Diesel, turbocharged No. of Cylinders 4 3 Displacement 135.2 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 59.9 hp 60 hp PTO Power 46.1 hp OOS: 45.6 hp; Cab: 42.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Dry type with safety element Fuel System Common rail direct injection Electronically controlled, high-pressure common rail Alternator Not Published OOS: 70 A; Cab: 110 A ▶ HydraulicsPump Type Engine-driven gear-type pump Tandem gear pump (implement + steering) Implement Flow Not Published 11.4 gpm Steering Flow Not Published 6.8 gpm Total Hydraulic Flow Not Published 18.2 gpm Overall Hydraulic Pump Flow 12x12 Power Shuttle: 12.7 gpm; HST: 12.6 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 12.1 gpm 11.4 gpm at a single rear SCV No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Up to 3 1 ▶ Fluid CapacityFuel Tank Capacity 14.0 gal OOS: 19.6 gal; Cab: 21.6 gal Coolant Capacity 7.08 qt Open operator station: 2.85 gal; Cab: 3.08 gal Crankcase Capacity 6.87 qt 9.0 qt (with filter) Transmission / Hydraulic System Capacity 12x12 Power Shuttle: 11.35 gal; HST: 9.25 gal 8.36 gal (9x3); 9.46 gal (12x12) Front Axle Fluid Capacity 9.0 qt DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side ▶ PTO & HitchPTO Type Independent, with soft-start feature Independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) Mid-PTO Availability Optional, 2,000 rpm (not offered with the 12x12 power shuttle) Not Published Category, 3-Point Hitch Category I with extendable ball ends Category 2, convertible to 1 Hitch Lift Capacity Not Published 3,968 lb Hitch Lift Capacity (at 24”) 12x12 Power Shuttle: 3,307 lb; HST: 3,086 lb 3,192 lb Lift Control Type Position and draft control Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic SyncShuttle (standard); PowrReverser (optional) No. of Speeds 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Max Travel Speed (Forward) Not Published 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) Max Travel Speed (Reverse) Not Published 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) Clutch Multiple stage wet type Wet traction clutch (PowrReverser) Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Internal wet disc brakes, individual control via independent foot pedals Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives 2WD or MFWD Front Axle Rating Not Published Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) Drawbar Capacity Not Published 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 12x12 Power Shuttle: 170.1 in; HST: 132.3 in 143.3 in Overall Width 12x12 Power Shuttle: 71.1 in; HST: 65.4 in Not Published Wheelbase 12x12 Power Shuttle: 80.3 in; HST: 77.9 in 80.7 in Ground Clearance 14.8 in Not Published Min. Turn Radius without Brakes Not Published 137.8 in (2WD); 183.1 in (4WD); 153.5 in (4WD, Carraro axle) Height to Top of ROPS 12x12 Power Shuttle: 103.2 in; HST: 102.4 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 12x12 Power Shuttle: 93.3 in; HST: 92.9 in Not Published ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 4,233 lb 5,445 to 6,702 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Ag / R3 Turf / R4 Industrial / Snow R1 Agricultural - Front 9.5x16 11L-15 R1 Agricultural - Rear 16.9x26 14.9-28 R3 Turf - Front 27x10.50-15 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) R3 Turf - Rear 44x18.00-20 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) R4 Industrial - Front 12-16.5 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 R4 Industrial - Rear 18.4-24 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 ▶ Loader & AttachmentsQuick Attach Loader System DL135: Skid steer quick attach 512 or 520M Loader Model DL135 512 or 520M Loader Lift Height DL135: 111 in 512: 113 in; 520M: 132 in Loader Lift Capacity (Full Height) DL135: 2,610 lb 512: 2,453 lb; 520M: 3,523 lb Loader Breakout Force DL135: 4,000 lb 512: 4,781 lb; 520M: 4,641 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
