▶ EngineEngine Manufacturer Simpson Kubota Engine Model SJV326 V3307-DI Engine Type 3-cylinder, turbocharged, intercooled 4-cylinder inline, direct injected diesel No. of Cylinders 3 4 Displacement 157.9 in³ 203 in³ Rated Engine Speed 2000 rpm 2600 rpm Engine Power (Gross) 55 hp Not Published PTO Power 45.3 hp 55 hp Engine Emissions Constraints Tier 4 Tier 2 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published 8 in dry, dual element Fuel System Electronically controlled high-pressure common rail Direct injection Alternator Not Published ROPS: 45 A, 12 V; Cab: 60 A, 12 V ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Not Published Implement Flow Not Published 11.0 gpm Steering Flow Not Published 6.1 gpm Total Hydraulic Flow 15.7 gpm 17.1 gpm (11.0 + 6.1, computed) Overall Hydraulic Pump Flow 15.7 gpm 17.1 gpm (11.0 + 6.1, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 10.6 gpm 11.0 gpm No. of Standard Remote Valves One 1 No. of Optional Remote Valves Not Published 2nd and 3rd optional ▶ Fluid CapacityFuel Tank Capacity 14.5 gal ROPS: 18.5 gal; Cab: 29.1 gal Coolant Capacity 4 gal 8.5 qt Crankcase Capacity 2.5 gal 11.6 qt Transmission / Hydraulic System Capacity 10.5 gal 59.2 qt Front Axle Fluid Capacity Not Published Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side ▶ PTO & HitchPTO Type Live Live, independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 rpm, 6-spline 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity 4,519 lb 4,189 lb Hitch Lift Capacity (at 24”) 2,755 lb 3,307 lb Lift Control Type Draft, position and response control Position, draft (top link sensing) and mix control ▶ Transmission & DrivetrainTransmission Type 8F x 2R SideShift sliding gear Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models No. of Speeds 8 forward and 2 reverse 8F/8R (12F/12R with optional creep) Max Travel Speed (Forward) Not Published 17.8 mph Max Travel Speed (Reverse) Not Published 18.0 mph Clutch Not Published Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Rear differential lock (bevel gears) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional Steering Hydrostatic steering with separate reservoir Hydrostatic power steering Brakes Oil-immersed wet disc Multiple wet disc, mechanical Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) Front Axle Type Straight adjustable (2WD) 4WD: bevel-gear type, on-the-go engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 73.2 in Wheelbase 80.7 in 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in Ground Clearance Not Published 15.4 in Min. Turn Radius without Brakes Not Published 2WD: 11.2 ft; 4WD: 11.8 ft Height to Top of ROPS 91.3 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 99.8 in Overall Length 138 in 2WD: 140.4 in; 4WD: 135.6 in ▶ WeightTractor Weight (Base) 4,894 lb 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard (ag): 6.00x16 front, 13.6x28 rear; optional (ag): 7.5x16 front, 16.6x28 rear Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear R1 Agricultural - Front 6.00x16 (7.5x16 optional) 2WD: 7.5-16; 4WD: 9.5-24 R1 Agricultural - Rear 13.6x28 (16.6x28 optional) 16.9-28 R3 Turf - Front Not Published 2WD: 29x12.5-15 or 27x9.5-15 R3 Turf - Rear Not Published 2WD: 21.5L-16.1 or 16.9-24 R4 Industrial - Front Not Published 12.5/80-18 (4WD) R4 Industrial - Rear Not Published 16.9-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling LA1153: two-lever quick coupler Loader Model FLx2815 LA1153 Loader Lift Height FLx2815: 111 in; 911X: 114 in LA1153 height position: 132.7 in; LA1153 power position: 117.2 in Loader Lift Capacity (Full Height) FLx2815: 2,810 lb (at pivot pin); 911X: 2,470 lb (at pivot pins) Not Published Loader Breakout Force FLx2815: 4,240 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
