▶ EngineEngine Manufacturer Shibaura Kubota Engine Model N4LDI-T V2403-CR-E5 Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 4 4 Displacement 135.2 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.8 hp 48.4 hp PTO Power Gear: 41.4 hp; HST: 39 hp 39 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Primary and secondary elements Dry type, primary and secondary element Fuel System Electronically controlled high-pressure common rail Direct injection Alternator 90 A 45 A, 12 V ▶ HydraulicsPump Type Gear-type single pump Not Published Implement Flow Not Published 7.8 gpm Steering Flow Not Published 4.7 gpm Total Hydraulic Flow 12.4 gpm 12.5 gpm (7.8 + 4.7, computed) Overall Hydraulic Pump Flow 12.4 gpm 12.5 gpm (7.8 + 4.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 Not Published No. of Optional Remote Valves 1 factory-installed; up to 3 field-installed Optional: double acting valve, or double acting valve with float position (float valve as second segment only) ▶ Fluid CapacityFuel Tank Capacity 14 gal 13.5 gal Coolant Capacity 1.66 gal 6.9 qt Crankcase Capacity 1.53 gal 8.7 qt Transmission / Hydraulic System Capacity 10.04 gal 10.6 gal Front Axle Fluid Capacity 2.21 gal 6.9 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged Live independent PTO with hydraulic clutch PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm Mid-PTO Availability No mid-PTO Not Published Category, 3-Point Hitch Category I and II SAE Category I Hitch Lift Capacity Not Published 2870 lb Hitch Lift Capacity (at 24”) 2,425 lb 2320 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST Hydrostatic transmission (3-range) No. of Speeds Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) 3-range Max Travel Speed (Forward) Not Published 15.8 mph Max Travel Speed (Reverse) Not Published 14.2 mph Clutch Dry single-disc Not Applicable Differential Lock & Limited Slip Options Mechanical engagement (Gear: right side heel pedal; HST: left side heel pedal) Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Internal wet disc, 2 pedals (Gear: right hand; HST: left hand) Mechanical, wet disc type Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1430 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133 in 120.3 in (without 3-point hitch) Overall Width 74 in 62.2 in Wheelbase 78 in 72.6 in Ground Clearance Not Published 15.2 in Min. Turn Radius without Brakes Not Published 8.5 ft (with brake applied) Height to Top of ROPS 104 in 91.7 in Height to Top of ROPS (folded) 80 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Gear: 3,836 lb; HST: 3,880 lb 3549 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 9.5x16 8.3-16 R1 Agricultural - Rear 13.6x28; 16.9x24 14.9-24 R3 Turf - Front 27x10.50-15 27X10.5-15 R3 Turf - Rear 44x18.00-20 44X18-20 R4 Industrial - Front 10-16.5 10.0-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System L135E: optional skid steer tool carrier LA766 2-Lever Quick Coupler Loader Model L135E LA766 Loader Lift Height L135E: 110.2 in 105.2 in Loader Lift Capacity (Full Height) L135E: 2,430 lb 1675 lb Loader Breakout Force L135E: 2,870 lb Not Published ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
