▶ EngineEngine Manufacturer Iseki LS Mtron Engine Model Iseki E4FH LS Mtron L3C19-T Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Water-cooled, 4-stroke common rail turbocharged diesel No. of Cylinders 4 3 Displacement 148.6 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 53.6 hp 52.8 hp @ 600 rpm PTO Power 40 hp 40 hp Engine Emissions Constraints Tier 4 Tier 4B Final Cooling System Type Liquid cooled Pressurized liquid w/ recirculating bypass Air Cleaner Dry Not Published Fuel System Common rail direct injection High pressure common rail (ECU controlled) Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Two gear-type pumps for steering and 3-point/remotes Gear Implement Flow 12.6 gpm 8.5 gpm Steering Flow 7 gpm HST: 6.3 gpm; Gear: 4.2 gpm Total Hydraulic Flow 19.6 gpm (12.6 + 7, computed) HST: 14.8 gpm; Gear: 12.7 gpm Overall Hydraulic Pump Flow 19.6 gpm (12.6 + 7, computed) HST: 14.8 gpm; Gear: 12.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 14.0 gal 11.0 gal Coolant Capacity 7.61 qt 2.3 gal Crankcase Capacity 7.82 qt 5.8 qt Transmission / Hydraulic System Capacity 10.04 gal 11.4 gal Front Axle Fluid Capacity 9 qt 2.2 gal ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Independent, electro-hydraulic engagement PTO Rear 540 rpm (1-3/8 in) 540 rpm Mid-PTO Availability Optional, 2,000 rpm Optional Category, 3-Point Hitch Category I and II Category I Hitch Lift Capacity 3,483 lb 2,756 lb Hitch Lift Capacity (at 24”) 3,086 lb 2,469 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle HST: 3-range hydrostatic; Gear: 16x16 No. of Speeds 12 forward and 12 reverse HST: 3-range; Gear: 16F/16R Max Travel Speed (Forward) Not Published HST: 15.63 mph; Gear: 16.8 mph Max Travel Speed (Reverse) Not Published HST: 11.37 mph; Gear: 15.3 mph Clutch Not Published HST: Not Applicable; Gear: Dry disc Differential Lock & Limited Slip Options Not Published Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Open station: vinyl-clad seat; standard cab: spring-suspension seat with armrests; deluxe cab: air-ride seat with armrests Not Published Front Axle Type Solid cast front axle 4WD (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Short: 2,317 lb; Regular: 1,598 lb; Extend: 1,091 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.3 in 142 in Overall Width 70.1 in 63 in Wheelbase Not Published 73 in Ground Clearance 14.0 in 15 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.4 in 96 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.9 in 91 in ▶ WeightTractor Weight (Base) ROPS: 4,035 lb; Cab: 4,420 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-28 standard; 16.9-24 optional 13.6-24 R3 Turf - Front 27x10.50-15 28X8.50-15 R3 Turf - Rear 44x18.00-20 41X14.00-20 R4 Industrial - Front 10-16.5 12X16.5 R4 Industrial - Rear 14.9-24; 17.5L-24 17.5LX24 ▶ Loader & AttachmentsQuick Attach Loader System FL2814: pin-type or skid steer 260TLA: New Holland Quick Mount; optional skid steer quick attach plates Loader Model FL2814 Not Published Loader Lift Height FL2814: 111 in 109 in Loader Lift Capacity (Full Height) FL2814: 2,570 lb 2,371 lb Loader Breakout Force FL2814: 3,910 lb 4,081 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 6-year limited powertrain, 2-year full coverage
