▶ EngineEngine Manufacturer AGCO Power Mahindra Engine Model 33 AWIC VNEM 373 Engine Type 3-cylinder, intercooled turbocharged diesel Turbocharged and intercooled, common-rail, liquid-cooled diesel (Tier 4 Final) No. of Cylinders 3 3 Displacement 201.4 in³ 161.7 in³ Rated Engine Speed 2200 rpm 2100 rpm Engine Power (Gross) 75 hp 71 hp PTO Power 60 hp 61 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Dual element (primary and secondary) Not Published Fuel System High-pressure common rail direct fuel injection Common rail direct injection Alternator 80 A Power Shuttle: 55 A; Power Shuttle Cab: 140 A ▶ HydraulicsPump Type Two-stage pump Not Published Implement Flow Not Published 11.1 gpm Steering Flow Not Published 4.6 gpm Total Hydraulic Flow Not Published 15.7 gpm Overall Hydraulic Pump Flow Not Published 15.7 gpm Hydraulic System Type Open center Open center, position and draft control, telescoping stabilizers and flex links Rear Remote Hydraulic Flow 17.2 gpm Not Published No. of Standard Remote Valves 2 Double auxiliary valves No. of Optional Remote Valves 1 3rd valve ▶ Fluid CapacityFuel Tank Capacity 33 gal 23.8 gal Coolant Capacity 4.2 gal Not Published Crankcase Capacity 3.3 gal Not Published Transmission / Hydraulic System Capacity Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Not Published Front Axle Fluid Capacity Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive Not Published ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement 2 speed independent push button type 1 PTO (wet clutch) PTO Rear 540/540E standard; 540/1000 optional 540 @ 1993 rpm and 540E @ 1469 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II CAT I & II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,850 lb 5,952 lb Lift Control Type Not Published Position and draft control ▶ Transmission & DrivetrainTransmission Type 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift Full synchro mesh speed and constant mesh range No. of Speeds 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 15F / 15R Max Travel Speed (Forward) 2WD: 18 mph; 4WD: 25 mph 21.4 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch with easy shift knob and electrohydraulic power shuttle lever Power shuttle with wet clutch and torsional damper Differential Lock & Limited Slip Options Hydraulic, electronically controlled; rear axle engaged via electrohydraulic rocker switch; 4WD front axle: hydraulic differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Cab: tilt and telescopic steering column; Platform: tilt steering column Hydrostatic power steering with tiltable steering column Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Oil immersed brakes, lever actuated parking brake Seat Suspension & Adjustability Cab: mechanical swiveling seat with armrests, air-suspension swivel seat optional; Platform: mechanical spring-suspension seat with armrests mComfort seat with contoured cushions, armrests and adjustable legroom; air-ride suspension seat in cab Front Axle Type Heavy-duty 2WD or 4WD front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 60.3 in (minimum, with std. 420/85R30 rear tires) 82 in Wheelbase 88.5 in 87.4 in Ground Clearance Not Published 15.5 in Min. Turn Radius without Brakes Not Published 12.5 ft (3.8 m) Height to Top of ROPS Not Published 106 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 115 in Overall Length Not Published 152.7 in ▶ WeightTractor Weight (Base) 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb 6,548 lb (6075 Power Shuttle); 7,495 lb (6075 Power Shuttle Cab) Weight with ROPS and Loader Not Published 8,428 lb (6,548 + 1,880, computed; 1,604.8 gal loader shipping weight) Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 420/85R30 standard Agricultural, Industrial R1 Agricultural - Front 2WD: 9.5L-15; 4WD: 320/85R24 11.2 x 24 R1 Agricultural - Rear 420/85R30 16.9 x 30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 43 x 16-20 R4 Industrial - Rear Not Published 18.4-28 ▶ Loader & AttachmentsQuick Attach Loader System 931X and 936X: universal skid steer type quick release Skid steer tool carrier system for ultra-fast attachments hookup Loader Model FL.3522, FL.3615, 931X, 936X 6075L Loader Lift Height FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) Loader 6075L: 133 in Loader Lift Capacity (Full Height) FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) Loader 6075L: 3,609 lb (at pivot pin) Loader Breakout Force Not Published Loader 6075L: 5,000 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year limited powertrain warranty
