▶ EngineEngine Manufacturer AGCO Power FPT Engine Model 33 AWI HD Not Published Engine Type 3-cylinder turbocharged and intercooled diesel 4-cylinder diesel No. of Cylinders 3 4 Displacement 201 in³ 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 100 hp 99 hp PTO Power 75 hp 85 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled (water-cooled) Liquid-cooled Air Cleaner 2-stage dry Not Published Fuel System Common rail direct injection High-pressure common rail electronic direct injection Alternator 95 A Not Published ▶ HydraulicsPump Type Single gear-type pump (tandem gear-type pumps with optional Twin Flow) Not Published Implement Flow 15 gpm standard; 26 gpm with optional Twin Flow 16.9 gpm Steering Flow Not Published 9.7 gpm Total Hydraulic Flow 26 gpm (Twin Flow: 15 gpm to 3-point hitch plus 11 gpm to remotes, combinable) 26.6 gpm (16.9 + 9.7, computed) Overall Hydraulic Pump Flow Not Published 26.6 gpm (16.9 + 9.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 15 gpm standard; 26 gpm with optional Twin Flow Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Up to 4 3 (3rd through Parts) ▶ Fluid CapacityFuel Tank Capacity 42 gal 42.3 gal Coolant Capacity 15.3 qt Not Published Crankcase Capacity 13.7 qt Not Published Transmission / Hydraulic System Capacity 17.2 gal Not Published Front Axle Fluid Capacity 5.3 qt axle beam; 0.85 qt each final drive Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement and speed selection Independent PTO Rear 540/540E standard; 540/540E/1000 optional Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II with flex link ends Hitch Lift Capacity 9,480 lb Not Published Hitch Lift Capacity (at 24”) 7,100 lb 4,339 lb (5,620 lb with auxiliary lift ram) Lift Control Type Electronic linkage control (ELC), position and draft control, lower link draft sensing Mechanical draft control (MDC), top link sensing (12x12); electronic draft control (EDC), lower link sensing (Hi-Lo cab) ▶ Transmission & DrivetrainTransmission Type Dyna-4 16x16 power shift and power shuttle (AUTO-DRIVE optional, 14:1 creeper optional) Not Published No. of Speeds 16F / 16R 12F/12R (20F/20R creeper, 24F/24R Hi-Lo or 40F/40R Hi-Lo creeper optional) Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-disc, foot pedal and electronic control Wet clutch (power shuttle and Hi-Lo) Differential Lock & Limited Slip Options Fully locking front and rear differentials, electro-hydraulically engaged Mechanical rear differential lock (12x12); electrohydraulic (Hi-Lo); MFD front axle with limited slip ▶ Chassis, Steering & ControlsFrame Type Rigid structural chassis, solid cast steel flanged rear axle with internal planetary reduction Not Published Steering Hydrostatic power steering, adjustable steering wheel Power steering Brakes Internal wet disc, hydraulic power assist, individual left and right foot pedals Wet disc Seat Suspension & Adjustability Mechanical suspended swivel seat standard; manual or automatic air suspension optional Air suspension seat with 15-degree swivel (optional); instructional seat (optional) Front Axle Type Adjustable 2WD or fixed cast steel 4WD, single piece with outboard planetary final drives HD 2WD, MFD or HD MFD with limited slip (12x12); HD MFD with limited slip (Hi-Lo) Front Axle Rating 2WD: 6,085 lb; 4WD: 10,500 lb Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 167.5 in 160 in (MFD cab) Overall Width 79.3 in 76 in (across standard fenders) Wheelbase 97.1 in 90 in (MFD) Ground Clearance 17.6 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 106 in (18.4R34 rear tires) Height to Top of ROPS (folded) Not Published 82.9 in (18.4R34 rear tires) Height to Top of Cab Model 108.5 in 102 in ▶ WeightTractor Weight (Base) 2WD: 8,426 lb; 4WD: 8,978 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 radial agricultural tires only; 16.9R38 rear is the speed chart basis (16.9R34, 16.9R30, 18.4R30, 18.4R34, 13.6R38 listed) R1 agricultural or turf, radial or bias; 18.4R34 rear reference tire R1 Agricultural - Front Not Published 7.50-16 (2WD); 11.2R24 or 14.9R24 (4WD) R1 Agricultural - Rear 16.9R38 18.4R34 (reference tire) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System MF931, MF941, MF946: Euro quick attach, single lever locking Not Published Loader Model MF931, MF941, MF946 L620; L630 Loader Lift Height MF931: 138 in; MF941: 148 in; MF946: 148 in L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL) Loader Lift Capacity (Full Height) MF931: 3,880 lb; MF941: 4,735 lb; MF946: 3,965 lb L620: 2,478 lb (NSL) / 3,179 lb (MSL); L630: 2,632 lb (NSL) / 3,428 lb (MSL) (at 31.5 in forward of pivot pin) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage 2-year/2,000-hour full coverage, all parts and labor Not Published
