▶ EngineEngine Manufacturer AGCO Power John Deere Engine Model 44 AWFC PowerTech 4045 PWL Engine Type 4-cylinder, intercooled turbocharged, liquid-cooled diesel Diesel, turbocharged, air-to-air aftercooled No. of Cylinders 4 4 Displacement 268.5 in³ 276 in³ Rated Engine Speed 2200 rpm 2100 rpm Engine Power (Gross) 100 hp 99.1 hp PTO Power Power Shuttle: 83 hp; Dyna-4: 76 hp 85 hp @ 100 rpm Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled (Cool-Gard II coolant) Air Cleaner Not Published Dry air cleaner, primary and secondary elements Fuel System High-pressure common-rail direct injection (HPCR) High pressure common rail (HPCR); electronic fuel control Alternator 80 A, 12 V OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V ▶ HydraulicsPump Type Two high-pressure gear pumps Tandem gear pump Implement Flow 15.1 gpm 18.4 gpm Steering Flow Not Published 6.3 gpm Total Hydraulic Flow 26 gpm 24.7 gpm Overall Hydraulic Pump Flow Not Published 24.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 26 gpm Not Published No. of Standard Remote Valves 2 2 (rear, Dual SCV) No. of Optional Remote Valves 1 3 rear valves total (3rd rear SCV optional); up to 3 mid SCVs (XI, XII, XIII) for loader functions ▶ Fluid CapacityFuel Tank Capacity 38.3 gal OOS: 29.6 gal; OOS (High Capacity): 37.2 gal; Cab: 37 gal; Cab (High Capacity): 44.9 gal Coolant Capacity Not Published OOS: 5.2 gal; Cab: 5.8 gal Crankcase Capacity Not Published 3.4 gal Transmission / Hydraulic System Capacity Not Published 10.4 gal Front Axle Fluid Capacity Not Published Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement via switch Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional PTO Rear 540 / 540E / 1000 rpm 540/540E rpm standard; 1000 rpm optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (convertible to I) Hitch Lift Capacity Not Published 5,305 lb standard; 6,114 lb optional Hitch Lift Capacity (at 24”) 7,710 lb 5,159 lb standard; 5,954 lb optional Lift Control Type Cab: electric controlled 3-point linkage with draft control; Platform: lever controlled 3-point linkage with draft control Mechanical or electrohydraulic; lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type Power Shuttle: 12F x 12R, 2 ranges, electro-hydraulic shuttle; Dyna-4: 16F x 16R powershift PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo; PowrQuad PLUS 16F/16R and Powr8 32F/16R also offered No. of Speeds Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse 16F/16R standard (PowrReverser); 32F/16R optional (PowrReverser Hi-Lo); 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) Max Travel Speed (Forward) 25 mph 16F/16R PowrReverser, top gear (D-4): 30K config: 18.64 mph; 40K config: 21.72 mph (480/70R28 Mitas rear tires, 2200 rpm) Max Travel Speed (Reverse) Not Published 16F/16R PowrReverser, top gear (D-4): 30K config: 20.54 mph; 40K config: 23.94 mph (480/70R28 Mitas rear tires, 2200 rpm) Clutch Wet clutch with easy shift knob and electrohydraulic power shuttle lever Wet Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock (rocker switch); hydraulic front differential lock on 4WD Electro-hydraulic rear differential lock, engage on the go ▶ Chassis, Steering & ControlsFrame Type Not Published Cast iron mid-frame Steering Cab: tilt and telescopic steering column; Platform: tilt steering column Not Published Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Not Published Seat Suspension & Adjustability Cab: air-suspension swivel seat; platform: mechanical spring-suspension seat with armrests OOS: isolated mechanical seat (fore/aft, weight, and lumbar adjustment); Cab: mechanical suspension seat standard, air suspension seat optional; adjustable weight range 88-330 lb Front Axle Type Heavy-duty 4WD front axle, center driveline MFWD Front Axle Rating Not Published 6,613 lb (MFWD, max permissible front axle load) Drawbar Capacity Not Published Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb ▶ Dimensions & ManeuverabilityOverall Width 64.8 in Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Wheelbase 95.7 in 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 102.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 102.9 in Overall Length Not Published 149.5 in ▶ WeightTractor Weight (Base) 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb 2WD, OOS: 8,140 lb; 2WD, Cab: 8,580 lb; MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (shipping weight, less weights) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 460/85R34 standard radial Not Published R1 Agricultural - Front Not Published 12.4R24 (320/85R24) R1W Radial R1 Agricultural - Rear Not Published 18.4R30 (460/85R30) R1W Radial R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 941X; 946X; FL.3723; FL.3819 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) Loader Lift Height 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in Loader Lift Capacity (Full Height) 941X: 2,220 lb; FL.3723: 2,840 lb (to full height, at 31.5 in forward of pivot pin) 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) Loader Breakout Force FL.3723: 5,819 lb; FL.3819: 4,893 lb 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
