▶ EngineEngine Manufacturer n/a Shibaura Engine Model n/a N3LDI-T Engine Type n/a 3-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders n/a 3 Displacement n/a 101.4 in³ Rated Engine Speed n/a 2600 rpm Engine Power (Gross) n/a 36.2 hp PTO Power n/a 27.5 hp Engine Emissions Constraints n/a Tier 4 Cooling System Type n/a Liquid-cooled Air Cleaner n/a Dry Fuel System n/a Common rail direct injection Alternator n/a Not Published ▶ HydraulicsPump Type n/a Engine-driven gear-type pump Implement Flow n/a 11.0 gpm Steering Flow n/a Not Published Total Hydraulic Flow n/a Not Published Overall Hydraulic Pump Flow n/a 12.6 gpm Hydraulic System Type n/a Open center Rear Remote Hydraulic Flow n/a 12.1 gpm No. of Standard Remote Valves n/a 2 No. of Optional Remote Valves n/a Up to 3 ▶ Fluid CapacityFuel Tank Capacity n/a 10.56 gal Coolant Capacity n/a 6.34 qt Crankcase Capacity n/a 4.86 qt Transmission / Hydraulic System Capacity n/a 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal Front Axle Fluid Capacity n/a 7.9 qt ▶ PTO & HitchPTO Type n/a Independent, with soft-start feature PTO Rear n/a 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability n/a Optional, 2,000 rpm Category, 3-Point Hitch n/a Category I with extendable ball ends Hitch Lift Capacity n/a 2,646 lb Hitch Lift Capacity (at 24”) n/a 2,535 lb Lift Control Type n/a Position and draft control ▶ Transmission & DrivetrainTransmission Type n/a 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds n/a 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Max Travel Speed (Forward) n/a Not Published Max Travel Speed (Reverse) n/a Not Published Clutch n/a Single stage dry type Differential Lock & Limited Slip Options n/a Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type n/a Not Published Steering n/a Power steering Brakes n/a Internal wet disc brakes, individual control via independent foot pedals Seat Suspension & Adjustability n/a Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering Front Axle Type n/a Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating n/a Not Published Drawbar Capacity n/a Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch n/a 122.0 in Overall Width n/a 64.2 in Wheelbase n/a 69.7 in Ground Clearance n/a 15.4 in Min. Turn Radius without Brakes n/a Not Published Height to Top of ROPS n/a 99.2 in Height to Top of ROPS (folded) n/a Not Published Height to Top of Cab Model n/a 91.3 in ▶ WeightTractor Weight (Base) n/a 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb Weight with ROPS and Loader n/a Not Published Weight with Cab and Loader n/a Not Published ▶ Tire OptionsTire Size & Options n/a R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front n/a 8-16 R1 Agricultural - Rear n/a 12.4x24 R3 Turf - Front n/a 27x8.50-15 R3 Turf - Rear n/a 41x14.00-20 R4 Industrial - Front n/a 10-16.5 R4 Industrial - Rear n/a 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System n/a DL125: Pin-on (skid steer quick attach optional) Loader Model n/a DL125 Loader Lift Height n/a DL125: 106 in Loader Lift Capacity (Full Height) n/a DL125: 1,660 lb Loader Breakout Force n/a DL125: 3,000 lb ▶ WarrantyWarranty Length & Coverage n/a 5-year powertrain warranty
