Massey Ferguson 1735M vs Massey Ferguson GC1723E

Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.

Across 0 measurable specs, this matchup is a dead heat: 0 categories to the Massey Ferguson 1735M, 0 to the Massey Ferguson GC1723E. Machine pages: Massey Ferguson 1735M and Massey Ferguson GC1723E.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Spec	Massey Ferguson 1735M	Massey Ferguson GC1723E
Engine HP (hp)	36.2 hp	n/a
PTO HP (hp)	27.5 hp	n/a
Weight (lb)	3,406 lb	n/a
Loader Lift (lb)	1,660 lb	n/a
3-Pt Lift (24 in) (lb)	2,535 lb	n/a
Lift Height (in)	106 in	n/a
Breakout Force (lbf)	3,000 lbf	n/a
Hydraulic Flow (gpm)	12.6 gpm	n/a

The headline numbers at a glance.

Massey Ferguson 1735MMassey Ferguson GC1723E

Engine HPhp

36.2 hp

n/a

PTO HPhp

27.5 hp

n/a

Weightlb

3,373 lb

▲3,406 lb

n/a

12x12 Power ShuttleHST

Loader Liftlb

1,660 lb

n/a

3-Pt Lift (24 in)lb

2,535 lb

n/a

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Massey Ferguson1735M	Massey FergusonGC1723E


Engine Manufacturer	Shibaura	n/a
Engine Model	Shibaura N3LDI-T	n/a
Engine Type	3-cylinder turbocharged intercooled diesel, liquid-cooled	n/a
No. of Cylinders	3	n/a
Displacement	101.4 in³	n/a
Rated Engine Speed	2600 rpm	n/a
Engine Power (Gross)	36.2 hp	n/a
PTO Power	27.5 hp	n/a
Engine Emissions Constraints	Tier 4	n/a
Cooling System Type	Liquid-cooled	n/a
Air Cleaner	Dry	n/a
Fuel System	Common rail direct injection	n/a
Alternator	Not Published	n/a

Pump Type	Engine-driven gear-type pump	n/a
Implement Flow	11.0 gpm	n/a
Steering Flow	Not Published	n/a
Total Hydraulic Flow	Not Published	n/a
Overall Hydraulic Pump Flow	12.6 gpm	n/a
Hydraulic System Type	Open center	n/a
Rear Remote Hydraulic Flow	12.1 gpm	n/a
No. of Standard Remote Valves	2	n/a
No. of Optional Remote Valves	Up to 3	n/a

Fuel Tank Capacity	10.56 gal	n/a
Coolant Capacity	6.34 qt	n/a
Crankcase Capacity	4.86 qt	n/a
Transmission / Hydraulic System Capacity	12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal	n/a
Front Axle Fluid Capacity	7.9 qt	n/a

PTO Type	Independent, with soft-start feature	n/a
PTO Rear	540 rpm (1-3/8 in 6-spline)	n/a
Mid-PTO Availability	Optional, 2,000 rpm	n/a
Category, 3-Point Hitch	Category I with extendable ball ends	n/a
Hitch Lift Capacity	2,646 lb	n/a
Hitch Lift Capacity (at 24”)	2,535 lb	n/a
Lift Control Type	Position and draft control	n/a

Transmission Type	12 x 12 power shuttle or 3-range hydrostatic	n/a
No. of Speeds	12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite	n/a
Max Travel Speed (Forward)	Not Published	n/a
Max Travel Speed (Reverse)	Not Published	n/a
Clutch	Single stage dry type	n/a
Differential Lock & Limited Slip Options	Mechanical engagement via right side heel pedal	n/a

Frame Type	Not Published	n/a
Steering	Power steering	n/a
Brakes	Internal wet disc brakes, individual control via independent foot pedals	n/a
Seat Suspension & Adjustability	Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering	n/a
Front Axle Type	Cast steel 4WD front axle with center drive line and bevel-gear final drives	n/a
Front Axle Rating	Not Published	n/a
Drawbar Capacity	Not Published	n/a

Overall Length with 3-Point Hitch	122.0 in	n/a
Overall Width	64.2 in	n/a
Wheelbase	69.7 in	n/a
Ground Clearance	15.4 in	n/a
Min. Turn Radius without Brakes	Not Published	n/a
Height to Top of ROPS	99.2 in	n/a
Height to Top of ROPS (folded)	Not Published	n/a
Height to Top of Cab Model	91.3 in	n/a

Tractor Weight (Base)	12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb	n/a
Weight with ROPS and Loader	Not Published	n/a
Weight with Cab and Loader	Not Published	n/a

Tire Size & Options	R1 Agricultural, R3 Turf, R4 Industrial	n/a
R1 Agricultural - Front	8-16	n/a
R1 Agricultural - Rear	12.4x24	n/a
R3 Turf - Front	27x8.50-15	n/a
R3 Turf - Rear	41x14.00-20	n/a
R4 Industrial - Front	10-16.5	n/a
R4 Industrial - Rear	17.5L-24	n/a

Quick Attach Loader System	DL125: Pin-on (skid steer quick attach optional)	n/a
Loader Model	DL125	n/a
Loader Lift Height	DL125: 106 in	n/a
Loader Lift Capacity (Full Height)	DL125: 1,660 lb	n/a
Loader Breakout Force	DL125: 3,000 lb	n/a

Warranty Length & Coverage	5-year powertrain warranty	n/a
