▶ EngineEngine Manufacturer Iseki Iseki Engine Model E3112 Not Published Engine Type 3-cylinder, liquid-cooled diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 68.5 in³ 68.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 22.5 hp 22.5 hp PTO Power 18.3 hp 18.7 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System Indirect injection Not Published Alternator 40 A Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 4.3 gpm 4.3 gpm Steering Flow 2.0 gpm 2 gpm Total Hydraulic Flow 6.3 gpm 6.3 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity 1.23 gal Not Published Crankcase Capacity 0.68 gal Not Published Transmission / Hydraulic System Capacity 2.9 gal Not Published Front Axle Fluid Capacity 1.05 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm (1.375 in, six spline) 540 rpm Mid-PTO Availability Independent, 2000 rpm (1 in, fifteen spline) Independent, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,191 lb 1,190 lb Hitch Lift Capacity (at 24”) 661 lb Not Published Lift Control Type Not Published Rate of drop control (standard) ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic with side-by-side foot pedals and cruise control 2-range hydrostatic with side-by-side foot pedals and cruise control No. of Speeds Infinite forward and reverse (2-range hydrostatic) 2-range hydrostatic Max Travel Speed (Forward) Not Published 9.1 mph (with R1 tires) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Locking rear differential (4WD) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Coil spring seat; retractable seat belt Front Axle Type 4WD front axle 4WD front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 46.7 in (minimum width, with R1 tires) 47.25 in Wheelbase 57.1 in 57.1 in Ground Clearance 6.7 in 6.7 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 72.8 in 72.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 97.6 in 97.6 in ▶ WeightTractor Weight (Base) 1,521 lb 1,433 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options AG, Turf or R4 Industrial: front 18x8.50-10, rear 26x12.00-12 Ag, turf or industrial: front 18x8.50-10, rear 26x12.00-12 R1 Agricultural - Front 18x8.50-10 18x8.50-10 R1 Agricultural - Rear 26x12.00-12 26x12.00-12 R3 Turf - Front 18x8.50-10 18x8.50-10 R3 Turf - Rear 26x12.00-12 26x12.00-12 R4 Industrial - Front 18x8.50-10 18x8.50-10 R4 Industrial - Rear 26x12.00-12 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer quick attach DL95: pin-on (factory or dealer installation) Loader Model FL1805 DL95 Loader Lift Height 74 in DL95: 72.8 in (at pivot pin) Loader Lift Capacity (Full Height) 922 lb DL95: 870 lb (at pivot pin) Loader Breakout Force 1,392 lb DL95: 920 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty 5-year powertrain warranty
